10.1Inch 1280×800 Lcd Touch Display 850Nits TM101JVHG32-01 LVDS Interface Industrial
10.1Inch 1280×800 Lcd Touch Display 850Nits TM101JVHG32-01 LVDS Interface Industrial
10.1Inch 1280×800 Lcd Touch Display 850Nits TM101JVHG32-01 LVDS Interface Industrial
10.1Inch 1280×800 Lcd Touch Display 850Nits TM101JVHG32-01 LVDS Interface Industrial
Specifications
Model Number :
TM101JVHG32-01
Place of Origin :
China
MOQ :
1
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
5000pcs/month
Delivery Time :
3-5 working days
Packaging Details :
factory original packing
Size :
10.1inch
Resolution :
1280(RGB)×800, WXGA
Luminance :
850 cd/m² (Typ.)
Viewing Angle :
88/88/88/88 (Typ.)(CR≥10)
Signal Interface :
LVDS (1 ch, 6/8-bit) , 20 pins Connector
Operating Temp.: :
-20 ~ 70 °C
Storage Temp :
-30 ~ 80 °C
Touch Type :
PCAP Touch
Application :
Industry Application
Description

10.1Inch 1280(RGB)×800, WXGA , 850Nits brightness Lcd Panel TM101JVHG32-01 LVDS Interface for Industrial use

TM101JVHG32-01 is a 10.1 inch diagonal a-Si TFT-LCD display panel with an integral WLED backlight system, With LED Driver , touchscreen PCAP. It features an operating temperature range of -20 ~ 70°C , a storage temperature range of -30 ~ 80°C . It's general features are summarized in the following: With Touch, Hight Brightness, WLED Backlight, Life ≥ 50K hours, With LED Driver, Reverse I/F, 6/8 bit , CTP Driver IC:ILI2511. Based on its features, JB recommend that this model be applied to Industrial, Outdoor High Brightness etc.
