10.1Inch LCD High Brightness Tft Display 1280×800 WXGA 500Nits P1010WXF1MB10
10.1Inch LCD High Brightness Tft Display 1280×800 WXGA 500Nits P1010WXF1MB10
Specifications
Model Number :
P1010WXF1MB10
Place of Origin :
China
MOQ :
1
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
5000pcs/month
Delivery Time :
3-5 working days
Packaging Details :
factory original packing
Size :
10.1inch
Resolution :
1280(RGB)×800, WXGA
Luminance :
500 cd/m² (Typ.)
Viewing Angle :
88/88/88/88 (Typ.)(CR≥10)
Signal Interface :
LVDS (1 ch, 6/8-bit) , 40 pins Connector
Operating Temp.: :
-20 ~ 70 °C
Storage Temp :
-30 ~ 80 °C
Application :
Industry and vehicle
Description

10.1Inch 1280(RGB)×800, WXGA , 500Nits brightness Lcd Panel P1010WXF1MB10 LVDS Interface for Industrial use

P1010WXF1MA01 is a 10.1" diagonal a-Si TFT-LCD display panel product with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of -20 ~ 70°C , a storage temperature range of -30 ~ 80°C . It's general features are summarized in the following: Wide Temperature, Ultra High Brightness, WLED Backlight, Life ≥ 50K hours, With LED Driver, 6/8 bit . Based on its features, JB recommend that this model be applied to Industrial, Outdoor High Brightness etc.

Brand
TIANMA
Model P/N
P1010WXF1MB10
Diagonal Size
10.1"
Panel Type
a-Si TFT-LCD, LCM
Resolution
1280(RGB)×800, WXGA 149PPI
Pixel Format
RGB Vertical Stripe
Active Area
216.96(W)×135.6(H) mm
Bezel Opening
219.96(W)×138.6(H) mm
Outline Size 229.8(W)×149(H)×9.61(D) mm Treatment Hard coating
Luminance 500 cd/m² (Typ.) Contrast Ratio 700 : 1 (Typ.) (TM)
Viewing Angle 88/88/88/88 (Typ.)(CR≥10) 10.1Inch LCD High Brightness Tft Display 1280×800 WXGA 500Nits P1010WXF1MB10 Response 25 (Typ.)(Tr+Td) ms
Good View at Symmetry Work Mode SFT, Normally Black, Transmissive 10.1Inch LCD High Brightness Tft Display 1280×800 WXGA 500Nits P1010WXF1MB10
Color Depth 262K/16.7M 50% NTSC Backlight WLED , 50K hours , With LED Driver
Mass - Used for
Refresh Rate 60Hz 10.1Inch LCD High Brightness Tft Display 1280×800 WXGA 500Nits P1010WXF1MB10 Touchscreen Without
Signal Type LVDS (1 ch, 6/8-bit) , 40 pins Connector
Voltage Supply 3.3V (Typ.)
Max. Ratings Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
