400cd/M2 Small LCD Touch Screen 800×480 WVGA 7inch Tft Lcd TM070RDH10-46
400cd/M2 Small LCD Touch Screen 800×480 WVGA 7inch Tft Lcd TM070RDH10-46
Specifications
Model Number :
TM070RDH10-46
Place of Origin :
China
MOQ :
1pc
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
5000pcs/month
Delivery Time :
5-8 working days
Packaging Details :
original factory packing
Size :
7inch
Resolution :
800(RGB)×480, WVGA
Luminance :
400 cd/m² (Typ.)
Viewing Angle :
70/70/50/70 (Typ.)(CR≥10)
Signal Interface :
Parallel RGB (1 ch, 6/8-bit) , 50 pins FPC
Operating Temp.: :
-20 ~ 70 °C
Storage Temp. :
-30 ~ 80 °C
Application :
Industry Application
Description

7Inch Resolution800(RGB)×480, WVGA Luminance400 cd/m² Operating Temp.: -20 ~ 70 °C Lcd Panel TM070RDH10-46

TM070RDH10-46 is a 7.0 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of -20 ~ 70°C , a storage temperature range of -30 ~ 80°C . It's general features are summarized in the following: WLED Backlight, U/D,L/R Reverse, 6/8 bit, Matte , 80.15mm length FPC. Based on its features, JB recommend that this model be applied to Industrial, Digital Photo Frame, Portable DVD Player etc

Brand
TIANMA
Model P/N
TM070RDH10-46
Diagonal Size
7.0"
Panel Type
a-Si TFT-LCD, LCM
Resolution
800(RGB)×480, WVGA 134PPI
Pixel Format
RGB Vertical Stripe
Active Area
154.08(W)×85.92(H) mm
Bezel Opening
157.08(W)×89.39(H) mm
Outline Size
164.9(W)×100(H) ×6(D) mm
Surface
Antiglare
Brightness
400 cd/m² (Typ.)
Contrast Ratio
500:1 (Typ.) (TM)
Viewing Angle
70/70/50/70 (Typ.)(CR≥10) 400cd/M2 Small LCD Touch Screen 800×480 WVGA 7inch Tft Lcd TM070RDH10-46
Display Mode
TN, Normally White, Transmissive
Best View on
6 o'clock
Response Time
25 (Typ.)(Tr+Td)
Display Colors
262K/16.7M 50% NTSC
Lamp Type
3S8P WLED , 20K hours , Without Driver
Frequency
60Hz 400cd/M2 Small LCD Touch Screen 800×480 WVGA 7inch Tft Lcd TM070RDH10-46
Touch Screen
Without
Panel Weight
155g (Typ.)
Application
400cd/M2 Small LCD Touch Screen 800×480 WVGA 7inch Tft Lcd TM070RDH10-46 400cd/M2 Small LCD Touch Screen 800×480 WVGA 7inch Tft Lcd TM070RDH10-46 400cd/M2 Small LCD Touch Screen 800×480 WVGA 7inch Tft Lcd TM070RDH10-46
Signal Interface
Parallel RGB (1 ch, 6/8-bit) , 50 pins FPC
Input Voltage
3.3/10.4/16.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL)
Environment
Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C
