ET Adapter 5.0 538-5051 CAT Perkins Electronic Service Tool 2021B

Introduction:

CAT Adapter 5.0 Communication Adapter 5.0 Diagnostic Kit 538.5051 is the latest generation of the CAT Communication Adapter group, and replaces the

CAT Comm Adapter III.This is the only recommended communication device for CAT,and the only datalink device that will allow you to properly communicate

with a CAT engine on dual datalinks. This function is needed for some CAT ET (Electronic Technician)

functions.

Attention:

CAT ET Adapter V Communication:

• Allows communication between service tools and engine controls using various data links such as J1939/11, DeviceNet (future release), CAT DataLink,

and J1708 (ATA) vehicle networks;

• Flash program allows adapter firmware upgrades as additional features become available;

• Uses J1587/J1708, high-speed data link (part of ADEM IV controls), substantially reducing flash times;

• Automatically selects J1587/J1708 when flashing the engine

Functions:

1. Display "Logged Event Codes" to show engine over speeds, high temperatures, fuel consumption, etc.

2. View ECM’s current configuration and change user settings.

3. Perform diagnostic tests and calibrations, and calibrate.

4. Electro-mechanical and electro-hydraulic components.

5. Context sensitive help leads operator through every task Cat ET can perform.

6. Data Logger and Data Log Viewer allows recording of ECM signals for delayed troubleshooting capability.

Functionalities Shows all operating conditions that cause high repair costs such as:Over speeds, high temperatures, fuel consumption, transmission shift counts.

This can provide awareness tochange operator.Cat "ET Trainer" is now included in ET Program. It allows Users to train and practice using Cat ET without a

Communications adapter or Electronic Control Module (ECM). This is a free feature of Cat ET.

Specifications:

1. ECM Summary screen lists every control module on equipment

2. Being tested and gives information on these modules.

3. Fast hookup and real time display of systems status. displays ,readings such as rpm, boost, pressures, temperatures, etc. for easy troubleshooting.

4. Identifies faulty sensors, harness connectors, and system parameters which are out of specification.

5. To help dealer identify problems without visiting machine.

6. Identifies intermittent sensors and wiring problems during Machine operation and keeps a record of each one, showswhen problem occurred and

how often it happened.

1. Added information to allow customer to assist dealer in diagnosing and repairing problems. (Troubeshooting help is not built in with in the program,

you will still need goback to books in order to follow a repair description and steps in each Fault Code display within the program).English and metric units

of measure integrated help file to easy learn the "How To" around the software.

The new ET5.0 generation configuration is as follows:
1: Adapter
2: 6-pin diagnostic cable
3: 9+14 diagnostic wiring harness
4: USB cable
5: 2019C+ registration machine
6: 10-digit factory password
7: Software U Disk 1PC
8: CD-ROM 1PC
9: High-quality tool box
