SK210 6 YN15V00017S003 Hydraulic Repair Parts For KobelcoTravel Motor
SK200-6 Travel Motor Repair Parts YN15V00017S003 Kobelco Excavator Hydraulic Parts
Description | SK200-6 Travel Motor Rotary Group, SK210-6 Hydraulic Repair Kit |
Application | Kobelco Excavator |
Model | SK210-6 |
Part No. | YN15V00017S003, YN15V00017S008,YN15V00009S005 |
Quality | OEM quality |
Weight | 10-15kgs |
Packing | Blank box or color box |
MOQ | 1PC |
Lead time | About 1-3 working days |
Payment | TT, Western union, Paypal, Paysend, RMB |
Warranty | 3 Months |
Shipping Port | Huangpu Old Port, Shenzhen Yantian,Guangzhou |
Parts on SK200-6 SK210-6 Travel Motor Group:
Pos. | Part No | Qty | Parts name | Comments |
---|---|---|---|---|
. . | YN15V00017F1 | [1] | MOTOR | KOB MOTOR ASSY (PROPELLING) Superseded by part number: YN15V00017F3 |
1. | YN15V00017S001 | [1] | BODY | KOB |
2. | YN15V00017S002 | [1] | COVER | KOB |
3. | YN15V00017S003 | [1] | BLOCK | KOB |
4. | NSS | [1] | NOT SOLD SEPARAT | CON RETAINER,SHOE |
5. | YN15V00009S005 | [3] | PLATE | KOB |
6. | YN15V00009S006 | [1] | PISTON | KOB |
7. | YN15V00009S007 | [4] | PLATE | KOB |
8. | YN15V00017S008 | [1] | PLATE | KOB |
9. | YN15V00017S009 | [1] | SHAFT | KOB |
10. | YN15V00017S010 | [1] | COUPLING | KOB |
11. | NSS | [1] | NOT SOLD SEPARAT | CON PLATE,SHOE |
12. | NSS | [1] | NOT SOLD SEPARAT | CON JOINT,BALL |
13. | YN15V00017S013 | [1] | SEAT | KOB |
14. | NSS | [9] | NOT SOLD SEPARAT | CON PISTON ASSY |
15. | YN15V00009S015 | [1] | RING | KOB Superseded by part number: YN15V00017S062 |
16. | YN15V00003S015 | [1] | O-RING | KOB Superseded by part number: YN15V00017S063 |
17. | YN15V00017S017 | [3] | CHECK VALVE | KOB |
18. | ZR26X03200 | [1] | SNAP RING | KOB Retaining -- ID 32 x OD 34.4 x Th 1.2mm |
19. | YN15V00009S019 | [1] | RING | KOB |
20. | YN15V00017S020 | [1] | PISTON | KOB |
21. | YN15V00017S021 | [1] | BALL | KOB |
22. | NSS | [2] | NOT SOLD SEPARAT | CON PIVOT |
23. | YN15V00003S024 | [1] | SEAL | KOB |
24. | PR30V00010S014 | [2] | ORIFICE | KOB |
25. | YN15V00009S027 | [1] | OIL SEAL | KOB |
26. | YN15V00017S026 | [3] | SPRING | KOB SPRING |
27. | 2441U820S31 | [9] | SPRING | KOB |
28. | YN15V00017S028 | [12] | SPRING | KOB |
29. | YN15V00017S029 | [1] | BEARING | KOB Superseded by part number: 86557434 |
30. | YN15V00017S030 | [1] | BEARING | KOB |
31. | ZS23C16045 | [8] | CAP,Hex Socket Head, M16 x 45mm | KOB Screw -- M16x2.0x45mm |
32. | YN15V00017S032 | [2] | SHIM | KOB |
33. | YN15V00017S033 | [1] | PIN | KOB |
35. | 2436U279S3 | [1] | PLUG | KOB |
36. | 2436U1427S25 | [10] | PLUG | KOB |
37. | 2436U1749S17 | [1] | PLUG | KOB PLUG |
38. | YN15V00017S038 | [3] | PLUG | KOB |
39. | 2436U1317S13 | [2] | PLUG | KOB |
40. | ZD12P00800 | [5] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOB ID 7.8mm x OD 9.7mm |
41. | ZD12P01100 | [4] | O-RING | KOB ID 10.8mm x OD 13.2mm |
42. | ZD12P01400 | [2] | O-RING | KOB ID 13.80 ± 0.19 x OD 18mm |
43. | YN15V00009S039 | [1] | O-RING | KOB |
44. | YN22V00013F1 | [2] | VALVE | KOB RELIEF SEE P.YN22V00013 |
45. | YN15V00017S045 | [1] | SPOOL | KOB |
46. | YN15V00017S046 | [1] | PLUG | KOB |
47. | 2436R874S5 | [1] | SPRING SEAT | KOB |
48. | 2436R874S6 | [1] | PIN | KOB |
49. | 2436R874S7 | [1] | SPRING | KOB |
50. | 2436R874S3 | [1] | FLEXIBLE JOINT | KOB |
51. | YN15V00017S051 | [1] | SPOOL | KOB |
52. | YN15V00017S052 | [2] | COVER | KOB |
53. | YN15V00017S053 | [2] | SPRING | KOB SPRING |
54. | YN15V00017S054 | [2] | SEAT | KOB |
55. | 2436U1384S8 | [2] | VALVE | KOB |
56. | 2483U223S4 | [2] | SPRING | KOB |
57. | 2436U1139S10 | [2] | PLUG | KOB |
58. | YN15V00017S058 | [2] | O-RING | KOB |
59. | ZD12P00900 | [2] | O-RING | KOB ID 08.80 ± 0.17 x OD 12mm |
60. | ZS23C12035 | [8] | SCREW,Hex Socket Head, M12 x 35mm | KOB M12x1.75x35mm |
. . | YN15V00017R100 | [1] | REPAIR KIT | KOB CONSISTS OF ITEM,14X9 |
. . | YN15V00017R200 | [1] | REPAIR KIT | KOB CONSISTS OF ITEM,11X1,22X2 |
. . | YN15V00017R300 | [1] | REPAIR KIT | KOB CONSISTS OF ITEM,4X1,12X1 |
