31N6 10050 R210 7 Hyundai Hydraulic Pump K3V112DT Hydraulic Pump Assembly
31N6 10050 R210 7 Hyundai Hydraulic Pump K3V112DT Hydraulic Pump Assembly
31N6 10050 R210 7 Hyundai Hydraulic Pump K3V112DT Hydraulic Pump Assembly
31N6 10050 R210 7 Hyundai Hydraulic Pump K3V112DT Hydraulic Pump Assembly
Specifications
Brand Name :
PNC
Model Number :
Hyundai R210LC-7
Place of Origin :
China
MOQ :
1PC
Price :
USD 1250-1350/SET
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
1000 set/month
Delivery Time :
1-3 working days
Packaging Details :
Standard export wooden case
Nc No :
NC-HP95
Model :
R210-7
Part No :
31N6-10010, 31N7-10011, 31N6-10050
Condition :
100% new
Warranty :
6 months
Stock :
Rich stock
Weight :
120-180 kgs
Product name :
R210-7 Hyundai Hydraulic Pump, K3V112DT Piston Hydraulic Pump
Description

31N6 10050 R210 7 Hyundai Hydraulic Pump K3V112DT Hydraulic Pump Assembly

R210-7 Hyundai Hydraulic Pump K3V112DT Hydraulic Pump Assembly 31N6-10050

Description

R210-7 Piston Hydraulic Pump, Hyundai Hydraulic Pump, K3V112DT

Application

R210LC-7 Excavator

Model

R210-7

Part No.

31N6-10010, 31N7-10011, 31N6-10050

Quality

100% new, China aftermarket or Korea

Weight

120-180 kgs

Packing

Pack into export wooden case

MOQ

1PC

Lead time

About 1-3 working days

Payment

TT, Western union, Paypal, Paysend, RMB

Warranty

6 Months

Shipping Port

Huangpu Old Port, Shenzhen Yantian,Guangzhou

Tips: To ensure client buy correct parts from China, parts details like model, part no. pump code, photo or size are required.

more details more good, all these infos are aim to supply you CORRECT parts to fit well with machine.

Hyundai R210LC-7 Hydraulic Pump Catalog:

Pos.

Part No

Qty

Parts name

Comments

*.

31N6-10010

[1]

MAIN PUMP ASSY

*-1,2,3,4

*.

31N6-10050

[1]

MAIN PUMP ASSY

*-1,2,3,4

*.

31N6-10051

[1]

MAIN PUMP ASSY

*-1,2,3,4

*-1.

@

[1]

MAIN PUMP UNIT

111.

XJBN-00077

[1]

DRIVE SHAFT(F)

113.

XJBN-00078

[1]

DRIVE SHAFT(R)

114.

XJBN-00351

[1]

COUPLING-SPLINE

123.

XJBN-00079

[2]

BEARING-ROLLER

123.

XJBN-00950

[2]

BEARING-ROLLER

124.

XJBN-00080

[2]

BEARING-NEEDLE

127.

XJBN-00081

[4]

SPACER-BEARING

NS141.

XJBN-00067

[2]

BLOCK-CYLINDER

NS151.

XJBN-00061

[18]

PISTON

NS152.

XJBN-00062

[18]

SHOE

*-11.

XJBN-01116

[1]

SET PLATE KIT

INCL153,156,158

153.

XJBN-00082

[2]

PLATE-SET

156.

XJBN-00353

[2]

BUSHING-SPHERICAL

156.

XJBN-00083

[2]

BUSHING-SPHERICAL

158.

XJBN-00354

[2]

SPACER

157.

XJBN-00084

[18]

SPRING-CYLINDER

211.

XJBN-00085

[2]

PLATE-SHOE

NS212.

XJBN-00070

[2]

PLATE-SWASH

S214.

XJBN-00071

[2]

BUSHING-TILTING

251.

XJBN-00086

[2]

SUPPORT

261.

XJBN-00087

[1]

COVER(F)-SEAL

271.

XJBN-00088

[2]

CASING-PUMP

312.

XJBN-00089

[1]

BLOCK-VALVE

S313.

XJBN-00065

[1]

PLATE-VALVE(R)

S314.

XJBN-00068

[1]

PLATE-VALVE(L)

401.

XJBN-00090

[8]

SCREW-HEX SOC HD

406.

XJBN-00355

[4]

SCREW-HEX SOC HD

466.

XJBN-00356

[2]

PLUG

468.

XJBN-00357

[4]

PLUG

490.

XJBN-00032

[18]

PLUG

NS531.

XJBN-00358

[2]

PIN-TILTING

532.

XJBN-00091

[2]

PISTON-SERVO

534.

XJBN-00092

[2]

STOPPER(L)

535.

XJBN-00093

[2]

STOPPER(S)

NS541.

XJBN-00073

[4]

SEAT

NS541.

XJBN-00859

[4]

SEAT

NS543.

XJBN-00074

[2]

STOPPER 1

NS543.

XJBN-00860

[2]

STOPPER

NS544.

XJBN-00076

[2]

STOPPER 2

NS544.

XJBN-00861

[2]

STOPPER

S545.

XJBN-00359

[4]

BALL-STEEL

NS548.

XJBN-00360

[2]

PIN-FEED BACK

K702.

XJBN-00918

[2]

O-RING

K710.

XJBN-00095

[1]

O-RING

K717.

XJBN-00096

[4]

O-RING

K724.

XJBN-00361

[16]

O-RING

K725.

XJBN-00362

[4]

O-RING

K728.

XJBN-00363

[4]

O-RING

K732.

XJBN-00912

[2]

O-RING

K774.

XJBN-00098

[1]

SEAL-OIL

789.

XJBN-00099

[2]

RING-BACK UP

792.

XJBN-00100

[2]

BACK-UP RING

806.

XJBN-00101

[2]

NUT

808.

XJBN-00364

[2]

NUT

824.

XJBN-00102

[2]

RING-SNAP

885.

XJBN-00103

[2]

PIN-VALVE PLATE

886.

XJBN-00365

[4]

PIN-SPRING

901.

XJBN-00104

[2]

BOLT-EYE

953.

XJBN-00105

[2]

SCREW-SET

954.

XJBN-00106

[2]

SCREW-SET

981.

XJBN-00156

[1]

NAME PLATE

981.

XJBN-00391

[1]

NAME PLATE

983.

XJBN-00341

[2]

PIN

*-2.

@

[1]

REGULATOR

SEE 4020

*-3.

@

[1]

GEAR PUMP

SEE 4030

*-4.

@

[1]

EPPR VALVE

SEE 4040

011.

XJBN-00060

[2]

PISTON SUB ASSY

SEE ILLUST

013.

XJBN-00063

[1]

CYLINDER ASSY(RH)

SEE ILLUST

014.

XJBN-00066

[1]

CYLINDER ASSY(LH)

SEE ILLUST

030.

XJBN-00069

[2]

SWASH PLATE SUB ASSY

SEE ILLUST

041.

XJBN-00072

[2]

CHECK VALVE ASSY 1

SEE ILLUST

042.

XJBN-00075

[2]

CHECK VALVE ASSY 2

SEE ILLUST

530.

XJBN-00366

[2]

TILTING PIN ASSY

SEE ILLUST

K.

XJBN-00971

[1]

PUMP UNIT SEAL KIT

SEE ILLUST
