11N7-10030 Coupling Hub R210-7 Metal Inset Hub Spline 12T For Hydraulic Pump
Description | ZX330 Coupling Hub, EC210 Metal Insert, R210-7 Hub Spline |
Application | Hyundai Crawler Excavator |
Model | ZX330-3, EC210,R210LC-7,E325C, R225-7 |
Part No. | 11N7-10030,VOE14515829, VOE14533207,4659041, 12T,13T,14T,16T,17T |
Size | 14T 40mm 100*32*46, 100*40*65/50, 12T 34mm 100*35*65/50mm |
Weight | 1.5-2kgs |
Packing | Carton box, plastic bag |
MOQ | 1PC |
Lead time | About 1-3 working days |
Payment | TT, Western union, Paypal, Paysend, RMB |
Warranty | 3 Months |
Shipping Port | Huangpu Old Port, Shenzhen Yantian,Guangzhou |
Parts on group R210-7 pump mounting:
Pos. | Part No | Qty | Parts name | Comments |
---|---|---|---|---|
2. | 11N6-12000 | [1] | HOUSING | |
3. | 11N7-10010 | [1] | COUPLING ASSY | |
3-1. | 11N7-10020 | [1] | ELEMENT | |
3-2. | 11N7-10030 | [1] | HUB-SPLINE | |
3-3. | 11N7-10040 | [4] | INSERT A | |
3-4. | 11N7-10050 | [4] | INSERT R | |
3-5. | S109-180606 | [4] | BOLT-SOCKET | |
3-6. | S109-180556 | [4] | BOLT-SOCKET | |
3-7. | 11N7-10060 | [2] | SCREW-CLAMP | |
3-8. | S472-500102 | [12] | PIN-SPRING | |
4. | S109-200506 | [4] | BOLT-SOCKET | |
5. | S017-100352 | [8] | BOLT-HEX | |
6. | S403-102002 | [12] | WASHER-PLAIN | |
7. | S017-100402 | [4] | BOLT-HEX |
Hydraulic pump coupling, excavator coupling we supply:
JCB220 80A | JRJ0213 KRJ3450 | coupling rubber |
110H ZX330-3 | 4646893 | coupling assy |
JCB220 E200B 14T | TFC80 | coupling assy |
R290-7 R360-7 JCB330 160H E330D/336D | 331/19919 324-4230 | coupling rubber |
R290-7 R360-7 JCB330 160H | 331/19919 287-0169 | coupling assy |
JCB160 50A | coupling hub+bolts | |
JCB220 E200B | TFC80 | coupling assy |
JCB160 50A | 331/25063 | coupling rubber |
JCB220 | K3V112 | spline 14t,d40mm |
JCB220 | TFC80 E200B | coupling assy 14t,d40mm |
K3V112 | spline | |
JCB160 50A | coupling hub+bolts | |
25H | 162*92mm | coupling assy-good quality |
JCB330/E330D/336D | 331/19919,160H 239-6479 324-4230 | coupling assy |
JCB220 | 80A JRJ0213 KRJ3450 20/950665, 331/19786 | rubber coupling |
R210 | JRJ0213,12T | coupling hub+bolts |
R210LC-7 ZX330-3 EC210 | 110H XKAH-00022 SA7117-30180 | сoupling assy |
JCB160 | 50A 331/25063 | сoupling assy |
CX130 | coupling + hub | |
DX180LC DX225LC DH220-5 | 2474-7009, 50H | element,coupling |
Solar 300LC-V | K9000426 / K9000994,160H | element,coupling |
JCB220 | JRJ0213 80A | rubber coupling |
JCB220 | TCF80, 14T 40mm | coupling assy |
R210 | 11E1-1508, 12T | hub |
JCB160 | 331/25063 | hub |
EC210 110H | 14515827 | coupling assy |
160H S300LC-V | K9000426 / K9000994 | coupling,element |
50H DX180LC DX225LC DH220-5 | 2474-7009 | coupling,element |
E325C,R225,ZX330-3, EC210/290 | 110H | coupling assy |
25A | coupling | |
45H ZX200 | YB00000114 | coupling assy |
EC210CL EC210/240 | 110H 14515827 | coupling assy |
R210-7 | 11N6-15010 110H | coupling assy |
R210-7 | 11N7-10020 110H | coupling |
R290-7 160H | 11E9-16012 160H | coupling assy |
R290-7 160H | K9000426 11E9-15091 | coupling |
12A | coupling | |
R210LC-7 K3V112DT | coupling assy, 110h | |
SK200-8 E215B | YN30P01023F1 | coupling assy- 90h |
JCB220 | TFC-80 | coupling |
SK60 | 30A | coupling |
SK60 | 30AS | coupling |
JS220 | JRJ0213 | coupling, 80a |
R290-7 | 11E9-15091 160H | coupling |
R480-9 R520-9 | 11NB-13030 240K | coupling |
R480-9 R520-10 | 11NB-13010 240K | coupling assy |
JS160 | 50A | hub with bolts |
R210-7 | 110H | coupling + hub with bolts |
Robex 55-3 | 11M6-55030 / 25AS | coupling, rubber |
S420LC-V | K9000426 / K9000994 160H | coopling,element |
S225LC-V | 2414-9008A 50H | coupling assy with hub,bolts |
110H-A | coupling assy (metal + rubber) | |
160H-A | coupling assy (metal + rubber) | |
JS330 | 331/19919,160H | coupling assy |
EX200-1 HPV116 | 4183167 | insert |
EX200-1 HPV116 | 4183166 | insert |
2474-7009 50H | rubber coupling | |
11N7-10020 110H | coupling, element | |
JCB220 | 80A | coupling |
JCB330 | 160H | coupling |
16AS | COUPLING | coupling assy |
110H | Rubber+iron | complete coupling |
50H | coupling element | |
JS240 JS260 | K3V112DT | coupling with hub |
