JEREL PTP 6-8gsm lacquer coated blister aluminum foil
JEREL PTP 6-8gsm lacquer coated blister aluminum foil
Specifications
Description

PRODUCT SPECIFICATION & PACKING

Product Name Blister aluminum foil/Pharmacitical aluminum foil/PTP aluminum foil

Alloy 8011 H state

Width≤600mm

Thickness 20mic, 25mic, 30mic

Construction(Unprinted) OP/ALU/VC; (Printed) OP/INK/ALU/INK/VC

ID 76mm/152mm(3 inches/6 inches)

ED 240mm

Length 1500m(20mic)

Weight 60g/㎡(20mic); 20kg/roll(250*0.02mm)

Density 2.7g/㎤

PackingPE film/Foam gasket/plastic plug/carton/pallet

Container load 20-25 tons in 20 GP container

JEREL PTP 6-8gsm lacquer coated blister aluminum foil

PRODUCT PERFORMANCE AND CHARACTERISTICS


1Primer (OP) is suitable for uvink, solvent ink, water based ink

2Heat sealing lacquer (vc) is suitable for ALU ALU FOIL/PVC /PP/PS/PET

3HSL 3-5g is suitable for Asian standards, 6-8g is suitable for European standards

4Printing colors: 1-3 colors, double-sided printing, full bottom with single color printing

5Water vapor transmission rate, national standard 0.5g/㎡24h

6Heat sealing strength 7.0N(PVC),6N(PVDC)


Blister Aluminum Foil is a kind of coated aluminum foil, used for cover lidding foil in pharma industry. It provides excellent properties such as of anti-oxygen, moisture-proof, leak-proof, carry-home, anti-pollution, etc.


Adopting hard anodized aluminum as cover material, blister foil is easy to break aluminum foil to take out the drugs by pushing the cover. Adopting heat-seal coating material, which cannot be stripped, PTP blister foil can be bonded with all kinds of plastic-based materials.


PRODUCT USAGE

Commenly heatsealed with PVC, PVDC, PP PET PE etc.
