Multi Color Mineral Water Bottle Automatic Hydraulic PET Plastic Preform Making Injection Mould Machine
Multi Color Mineral Water Bottle Automatic Hydraulic PET Plastic Preform Making Injection Mould Machine
Multi Color Mineral Water Bottle Automatic Hydraulic PET Plastic Preform Making Injection Mould Machine
Multi Color Mineral Water Bottle Automatic Hydraulic PET Plastic Preform Making Injection Mould Machine
Multi Color Mineral Water Bottle Automatic Hydraulic PET Plastic Preform Making Injection Mould Machine
Multi Color Mineral Water Bottle Automatic Hydraulic PET Plastic Preform Making Injection Mould Machine
Multi Color Mineral Water Bottle Automatic Hydraulic PET Plastic Preform Making Injection Mould Machine
Multi Color Mineral Water Bottle Automatic Hydraulic PET Plastic Preform Making Injection Mould Machine
Specifications
Brand Name :
DAWSON
Model Number :
PET230S/1000
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
USD 27,500 ~ 29,000 / set
Payment Terms :
L/C, T/T
Supply Ability :
200 sets / month
Delivery Time :
5-8 weeks
Packaging Details :
Standard Export Packing
Clamping force :
2300 KN
Injection weight :
1006g (PET)
Space between tie bar :
520*520mm
Mould thickness :
200~530mm
Platen stroke :
475mm
Warranty :
12 month
Style :
Horizontal
Screw diameter :
62mm
Plasticizing capacity :
270 g/s
Preform neck :
20~120mm
Output :
2000~3500 pcs/h
Language :
English or other specified
Description

Multi Color Mineral Water Bottle Automatic Hydraulic PET Plastic Preform Making Injection Mould Machine

Multi Color Mineral Water Bottle Automatic Hydraulic PET Plastic Preform Making Injection Mould Machine

Multi Color Mineral Water Bottle Automatic Hydraulic PET Plastic Preform Making Injection Mould Machine

DAWSON MACHINERY & MOULD GROUP
Injection Molding Machine
Specialized for making PET preforms , caps , pails, buckets, jars, covers, lids.
Special screw for PET products, all machine adapt latest Taiwan control system,
Japan YUKEN hydraulic valve for highest quality standard and machine performance.
We also able to provide mould designing and manufacturing to help you build up all kinds of plastic items manufacturing.

Multi Color Mineral Water Bottle Automatic Hydraulic PET Plastic Preform Making Injection Mould Machine

Multi Color Mineral Water Bottle Automatic Hydraulic PET Plastic Preform Making Injection Mould MachineMulti Color Mineral Water Bottle Automatic Hydraulic PET Plastic Preform Making Injection Mould Machine

Technical Parameters
Parameters
PET170S/530
PET230S/1000
PET270S/1000
PET270S/1500
Screw diameter
mm
50
62
62
70
Theoretical shot volume
cm3
450
860
860
1300
Shot weight
g
527
1006
1006
1521
Clamping force
KN
1700
2300
2700
2700
Toggle stroke
mm
435
475
540
540
Ejector stroke
mm
135
140
150
150
Space between tie bars
mm
460 * 460
520 * 520
570 * 570
570 * 570
Mould thickness
mm
180 ~ 500
200 ~ 530
200 ~ 550
200 ~ 550
Motor power
kw
28
36
43
56
Machine size
m
5.5 * 1.4 * 2.1
6.14 * 1.5 * 2.14
6.34 * 1.6 * 2.25
7.21 * 1.7 * 2.37
Machine weight
ton
6.5
7.5
8.5
9

Details Images

DAWSON MACHINERY & MOULD GROUP

Starting Business since 2003!
Our injection molding machines are sold to all over the world, to many South America, Asia, Africa countries.
Local service team in Saudi Arabia, Colombia, Panama, South Africa ...
Multi Color Mineral Water Bottle Automatic Hydraulic PET Plastic Preform Making Injection Mould Machine
Located in Zhangjiagang city, we are experienced in injection molding machine project. Help a lot of customers build their own business and production line.
Professional aftersale team solve your problems during production.
DAWSON will be your reliable friend in China, and we will always do our best to give you max support!
