Plastic Cans Injection Stretch Blow Molding Machine / PET Bottle Making Machinery
Plastic Cans Injection Stretch Blow Molding Machine / PET Bottle Making Machinery
Plastic Cans Injection Stretch Blow Molding Machine / PET Bottle Making Machinery
Plastic Cans Injection Stretch Blow Molding Machine / PET Bottle Making Machinery
Plastic Cans Injection Stretch Blow Molding Machine / PET Bottle Making Machinery
Plastic Cans Injection Stretch Blow Molding Machine / PET Bottle Making Machinery
Specifications
Brand Name :
Dawson
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
USD75000-80000
Payment Terms :
L/C, T/T
Screw Diameter :
40mm
Screw L/D Ratio :
20.5:1
Screw Speed :
0-190RPM
Theoretical Injection Capacity :
238cm3
Injection Pressure :
174Mpa
Max. Hydraulic Pressure :
140Kg/cm
The Actual Injection Quantity(PS): :
225g(ps)/8Oz
Max. Pump Pressure: :
16Mpa
Motor Oil :
18.5Kw
Electric Power :
12.2kw
Description

Plastic Cans Injection Stretch Blow Molding Machine / PET Bottle Making Machinery

In this machine, there are three operational stations: injection perform, blowing/stretching, and product release. The process starts with raw material being transferred from the hopper into the injection screw, creating preforms. The preforms are then moved to the blow/stretch station, where they are shaped using their residual heat without additional reheating. Following this, the completed products are rotated to the release station, where they are automatically released. This machine features a fully automated rotation cycle, which avoids the need for preform purchases, minimizes waste, and offers high levels of automation with smoothly finished products.
