Electric Actuator High Pressure Two Piece Ball Valve Full Port Double Flange Ends
Electric Actuator High Pressure Two Piece Ball Valve Full Port Double Flange Ends
Electric Actuator High Pressure Two Piece Ball Valve Full Port Double Flange Ends
Electric Actuator High Pressure Two Piece Ball Valve Full Port Double Flange Ends
Specifications
Brand Name :
JIEYU
Certification :
API ISO Ts CE
Place of Origin :
Wenzhou China
MOQ :
1PC
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000PCS/Mouth
Delivery Time :
7-30 work days
Packaging Details :
Plywood Case
Body Material :
CF8/CF8M/CF3/CF3M
Valve Material :
CF8
Size :
DN15~DN200
Connection :
CE
Standard :
GB
Pressure :
PN40
Description

Electric Actuator High Pressure Full Port Two Piece Ball Valve Double Flange Ends

Specifications

High Platform Ball Valve

Applicable Standards:
- Design and Manufacturing:GB12237-89
- Connection:JB/T79
- Fireproof Test: API607 4th 1993
- Test and Inspection:GB/T13927-1992
Size Range:
- DN15~DN200
Pressure Rating:
- GB PN16 PN25 PN40
Temperature Range:
- -20°C~185°C

Ball valve, the opening and closing member (sphere) is driven by the valve stem and rotates around the axis of the ball valve. It can also be used for fluid regulation and control. The multi-way ball valve not only can flexibly control the confluence, splitting, and flow direction switching of the medium, but also can close any channel and connect the other two channels.

PN(Mpa)DNLφEφBφCTfN-φhHH1WMPA1A2B1B2
1.6151309565451424-14487913599663642
2014010575551424-14538413599663642
2515011585651424-1464951701111674250
32165135100781624-18711031701111674250
40180145110851634-18761112001414795070
502001601251001634-18851202001414795070
65Contact us freely
80
100
125
150
200


Application

Ball valves are widely used in petroleum refining, long-distance pipelines, chemical, paper, pharmaceutical, water conservancy, electric power, municipal, steel and other industries.

Advantage

1. Small fluid resistance: pneumatic ball valve is the smallest of the fluid resistance of all valve classification, even the reduced diameter pneumatic ball valve, its fluid resistance is quite small.
2. Stem seal is reliable: Since the valve stem only rotates and does not move up and down, the packing seal of the valve stem is not easy to break, and the sealing capacity increases with the increase of the medium pressure.
3. The sealing performance of the valve seat is good: the sealing ring made of elastic material such as PTFE is easy to seal, and the valve sealing ability of the pneumatic ball valve increases with the increase of the medium pressure.

Model Selection

High Pressure Ball Valve

StandardANSIGBJISDIN
Pressure150LB/300LBPN16/PN2510K/20KPN16/PN25/PN40
Matreial1) CF8/SS304 2) CF8M/SS316 3) CF3/SS304L 4) CF3M/SS316L 5) WCB
Model1) High Platform Model 2) Handle Model
