Digital P5 Full Color Outdoor LED Displays SMD Waterproof Cabinet 960MM X 960MM
Digital P5 Full Color Outdoor LED Displays SMD Waterproof Cabinet 960MM X 960MM
Digital P5 Full Color Outdoor LED Displays SMD Waterproof Cabinet 960MM X 960MM
Digital P5 Full Color Outdoor LED Displays SMD Waterproof Cabinet 960MM X 960MM
Specifications
Brand Name :
Jinhe
Model Number :
P5
Certification :
CE/ROHS/FCC
Place of Origin :
China
MOQ :
1 square meter
Price :
Negotiable
Payment Terms :
T/T, Western Union
Delivery Time :
15 working days after receiving the deposit
Packaging Details :
Wooden case, flight case
Pixel Pitch :
5mm
Module Size :
160*160
Module Resoultion :
32*32
Pixel Density :
40000dots/㎡
Brightness :
≥7000nits
Scan Mode :
1/8scanning
Description

Digital P5 Full Color Outdoor LED Displays SMD Waterproof Cabinet 960MM X 960MM

Specifications:

※ Module parameter
Technical parameters UNIT Parameters
Pixel pitch MM 5
Physical density /M2 40000
Pixel configuration RGB 1R1G1B
Driving method Constant current 1/8scan
Module resolution DOTS 32X16=512Dots
Module port HUB75-D
※ Led display parameter
Viewing angle Deg. H140 V120
Viewing distance M 5-20
Maximum power W/ M2 1000
Refresh frequency HZ ≥500
Equilibrium brightness CD/ M2 ≥7000
Working environment temperature 0C -30~+65
Working environment humidity RH 10%-90%
Gray scale/color ≥16.7M color
Input signal RF S-Video RGB etc
Life time HOURS 100000
Lamp failure frequency ＜0.0001
IP rating IP65
Supply mode

AC220V/50HZ Or AC110V/60HZ
DC power supply G-energy 5V 40A

Features:

1. 40000 pixel dots per square meter resolution.

2. With super-high brightness LED, high contrast.

3. Unequalled high brightness and stable performance lead long lifespan and low power consumption.Accurate color uniformity and smoother,flicker-free video displaying.

4. 16,777,216 colors combine with 256 level gray scale by each Red,Green,and Blue LED.

5. Extreme viewing angle by 3 IN 1 SMD,better color mixture and gorgeous image quality.

6. Latest LED technology and control method accepted, make excellent performance with attractive price.

7. With the performance of high brightness, low attenuation, long lifetime and high reliability.

8. We provide good pre -sale service and after -sale service.

Applications:

Business Organizations supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.
Financial Organizations

Banks, negotiable securities, funds, insurance companies, pawnshops;

Non-profit Organizations: Telecommunications, post offices, hospital, schools;
Public Places subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers; Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms
Entertainments Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course

Pre-sales service :
Our team design and make solutions based on different requirements from different customers, what you think is what we can do.
After-sales services:
1. We provide customer service through Skype, phone or email, supply you video or drawing to solve problems.
2. We provide remote control service through internet to achieve real time service, which will short time of solving problems.
3. We provide one professional engineer to one customer to keep fastly reply.
Installation Service:
1. We provide detailed CAD drawing to customer for preparing metal structure.
2. We could dispatch our engineer to your place , guide installation and free training.
3. Special designs have special solutions; we will make perfect solutions to satisfy all customers' requirements
