High Resolution P6 Outdoor LED Display Full Color Screens 6mm Pixel Pitch
High Resolution P6 Outdoor LED Display Full Color Screens 6mm Pixel Pitch
Specifications
Brand Name :
Jinhe
Model Number :
P6
Certification :
CE/ROHS/FCC
Place of Origin :
China
MOQ :
1 square meter
Price :
Negotiable
Payment Terms :
T/T, Western Union
Delivery Time :
15 working days after receiving the deposit
Packaging Details :
Wooden case, flight case
Pixel Pitch :
6 mm
Module Size :
192 * 192
Module Resoultion :
32 * 32
Pixel Density :
27777 dots/㎡
Brightness :
≥7000nits
Usage :
Outdoor
Description

High Resolution P6 Outdoor LED Display Full Color Screens 6mm Pixel Pitch

Specifications:

led parameter
Pitch size 6mm
Module size 192mm*192mm
Module pixel(dots) 32*32
Pixel configuration 1Red,1Green,1Blue SMD 3-in-1
LED chip Silan/Cree/Nichia
Color scale 65536degree/1.07 billion colors
Pixel density 27777pixels/square meter
View angle(H/V) 120/120degree
Brightness ≥1200cd/sqm
Brightness adjustment 100level automatic or manual
View distance 5--80m
Power consumption 100-1200W/sqm
Net weight <45kg/square meter
Operating temperature —45°C~+80°C
Operating humidity 10%—95%RH
Life time ≥100,000hours
Out of control dot ≤3/10,000
Whole Display Flatness ≤1mm Juncture
Exchange frame speed >150frames per second
Refresh frame frequency 600Hz
Control distance Cat. 5: 120m (without repeater), single mode fiber:20km,multi mode fiber: 500m
Power 110V/220V±15% 50Hz
Operating system Windows98/Me/2000/Xp
Drive mode constant current driving, static scan
Display mode VGA640X480—VGA1600X1024
Protections for outdoor display IP65 for front, IP64 for rear
Maintenance way rear access, haging installation
Accepting signal PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI

Features:

1. color spots or picture shade will be removed through the adjustment of brightness and color by each independent pixel

2, adopted with self developed steel structure and special kits will be kept in good flatness and smoothness

3, strict water proof testing by Ip65

4, according to environmental changes the brightness can be adjusted automatically for energy saving

5, special PVC kits are adopted to protect from corrosion according to coastal weather

6, according to environmental changes the brightness can be adjusted automatically for energy saving

7, auto power on/off, work unattended

Applications:

Business Organizations supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.
Financial Organizations

Banks, negotiable securities, funds, insurance companies, pawnshops;

Non-profit Organizations: Telecommunications, post offices, hospital, schools;
Public Places subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers; Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms
Entertainments Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course

Our services:

Sage warrants our Indoor & Outdoor Full Color LED Display Screens to be free from defects in materials and workmanship for a period of two years from the date of purchase.

This warranty is limited to the repair or replacement of a defective part. Claims under this warranty must be accompanied by a photo of the defective part, a description of the defect, and a receipt from the original purchaser. The warranty does not cover normal wear and tear, improper assembly, damage or failure due to accident.

Sage provides the service of software upgrading free of charge.

Sage provides online technology support for technical consultant, trouble shooting and repairing contact.

This warranty applies only to the original owner and is not transferable
Welcome to your inquiry! :-)
