P10 Video Outdoor Smd LED Display Full Color Screens CE ROHS Certification
P10 Video Outdoor Smd LED Display Full Color Screens CE ROHS Certification
P10 Video Outdoor Smd LED Display Full Color Screens CE ROHS Certification
P10 Video Outdoor Smd LED Display Full Color Screens CE ROHS Certification
P10 Video Outdoor Smd LED Display Full Color Screens CE ROHS Certification
P10 Video Outdoor Smd LED Display Full Color Screens CE ROHS Certification
P10 Video Outdoor Smd LED Display Full Color Screens CE ROHS Certification
P10 Video Outdoor Smd LED Display Full Color Screens CE ROHS Certification
Specifications
Brand Name :
Jinhe
Model Number :
JH-002
Certification :
CE/ROHS/FCC/SGS
Place of Origin :
China
MOQ :
40pcs
Price :
negotiation
Payment Terms :
T/T or western Union
Supply Ability :
3,000pcs per month
Delivery Time :
10 working days after received your payment
Packaging Details :
Carton, wooden case, flight case, according to customer’s request.
Product Name :
Outdoor led display
Size Of cabinet :
960mm*800mm
Brightness :
1200cm/d
Physical density :
10000/M2
Application :
outdoor
Viewing angle :
H120 V120
Driving method :
Constant current 1/4scan
Resolution of cabinet :
96*80
Description

P10 Video Outdoor Smd LED Display Full Color Screens CE ROHS Certification

※ Module parameter
Technical parameters UNIT parameters Values
Pixel pitch MM 10
Physical density /M2 10000
Pixel configuration RGB 1R1G1B
Driving method Constant current 1/4scan
Module resolution DOTS 32X16=512Dots
Module port HUB75-D
※ Led display parameter
Viewing angle Deg. H110 V110
Every square meter module PCS 19.5
Maximum power W/ M2 800
Refresh frequency HZ ≥600
Equilibrium brightness CD/ M2 ≥7000
Working environment temperature 0C -30~+65
Working environment humidity RH 10%-90%
Gray scale/color ≥16.7M color
Input signal RF S-Video RGB etc
Life time HOURS 100000
Lamp failure frequency ＜0.0001
IP rating IP65

Features:

1. 10000 pixel dots per square meter resolution.

2. With super-high brightness LED, high contrast.

3. Unequalled high brightness and stable performance lead long lifespan and low power consumption.Accurate color uniformity and smoother,flicker-free video displaying.

4. 16,777,216 colors combine with 256 level gray scale by each Red,Green,and Blue LED.

5. Extreme viewing angle by 3 IN 1 SMD,better color mixture and gorgeous image quality.

6. Latest LED technology and control method accepted, make excellent performance with attractive price.

7. With the performance of high brightness, low attenuation, long lifetime and high reliability.

8. We provide good pre -sale service and after -sale service.

Applications:

Business Organizations supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.
Financial Organizations

Banks, negotiable securities, funds, insurance companies, pawnshops;

Non-profit Organizations: Telecommunications, post offices, hospital, schools;
Public Places subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers; Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms
Entertainments Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course

Frequently asked questions:

1. How long have your company run on led display?
5 years focusing on led display field, 3 years exporting experience.

2. Which payment terms are you accept?

T/T, Paypal, Western Union or Bank transfer.

3. Are your company a trading one or a factory?
Factory and trade (we have our own factory.)

4. After an order is placed, when to deliver?
It depends on whether the products you buy has inventory. If we have inventory, generally we can arrange shipment after 2 to 3 days.If not, it will be decided by the time of the factory production.

5. What about the cooperation process?
Confirm details of order, 30% deposit, Arrange inventory, pay the balance, shipment.

6. What is your terms of delivery?
After we receive the 30% advance , 5days~15 days later can load goods
