RGB High Resolution Rental LED Screens HUB75 Module Port Two years Warranty
RGB High Resolution Rental LED Screens HUB75 Module Port Two years Warranty
Specifications
Brand Name :
Jinhe
Model Number :
P6
Certification :
CE/ROHS/FCC
Place of Origin :
China
MOQ :
1 square meter
Price :
Negotiable
Payment Terms :
T/T, Western Union
Delivery Time :
15 working days after receiving the deposit
Packaging Details :
Wooden case, flight case
Pixel Pitch :
6 mm
Module Size :
192 * 192 mm
Scan Mode :
1/8 scanning
Pixel Configuration :
1R1G1B
Module Port :
HUB75
Warranty :
Two years
Description

RGB High Resolution Rental LED Screens HUB75 Module Port Two years Warranty


Specifications:

※Module parameters
Technical parameters UNIT parameters
Pixel pitch MM 6
Panel size MM 384 * 192 or 192 * 192 mm
Physical density /M2 27777
Pixel configuration R/G/B 1,1,1
Driving method Constant current 1/16 scan or 1/8 scan
LED Encapsulation SMD 3528 white light
Display resolution DOTS 64 * 32 = 2048 32 * 32=1024
Module weight KG 0.28
Module port HUB75-B
Module working voltage VDC 5
Module consumption W 30
※Screen parameters
Viewing angle Deg. 140 °
Option distance M 6-60
Driving device 2026/5020
Every square metre module PCS 13.56
Maximum power W/ M2 600
Frame Frequency HZ/S ≥60
Refresh frequency HZ/S ≥600
Equilibrium brightness CD/ M2 ≥1800
Working environment temperature 0C -10~60
Working environment humidity RH 10%～70%
Display working voltage VAC AC46～54HZ,220V±15%/110V±15%
Colour temperature 8500K-11500K
Gray scale/color ≥16.7M color
Input signal RF S-Video RGB etc
Control system PCTV nonlinearity card,DVI display card,Linsn control system
Mean free error time HOURS ＞5000
Life span HOURS 100000
Lamp failure frequency ＜0.0001
Antijam IEC801
Safety GB4793
Resist the electricity 1500V last 1min No breakdown
Cabinet weight KG/ M2 40 (standard steel box)
Earth leakage current mA
IP rating The back IP40,The front IP50
Cabinet size mm 768*768 (can be customized)




Features:

1. Easy to install and disassemble.

2. Adjustable brightness: The brightness can be adjusted according to your application and surrounding lighting conditions. In doing so, you can not only save power, but also be in control to maintain high-quality image displays.

3. Automatic backup system: Our LED Displays could utilize two computers to ensure interruption-free display of images and videos. For instance, if one unit was to shutdown due to technical issues, the other unit acts as a back-up solution automatically.

4. The better quality/price ratio in LED Displays field.

5. All-weather designs:With an IP 65 rating, our cabinets offer ventilation and protection from rain or water damage.

6. High refresh rates:With high refresh rates, our products can display flicker-free video images – including live video feeds.





Applications:

This kind of LED full color mobile led display screen is appliled for advertising, city beautifying, information publicity, great concerns and relative activities.

1: Outdoor advertising, digital billboards, advertising in big companies

2: Sports halls, fields, playgrounds.

3: Airports, bus stations and railway passenger terminals.

4: Facades of shopping malls, department stores, banks and car dealerships.

5: Architecture and social projects, information systems in cities.

6: Show-business, concerts, festivals, motor shows and other public events.

Pre-sales service :
Our team design and make solutions based on different requirements from different customers, what you think is what we can do.
After-sales services:
1. We provide customer service through Skype, phone or email, supply you video or drawing to solve problems.
2. We provide remote control service through internet to achieve real time service, which will short time of solving problems.
3. We provide one professional engineer to one customer to keep fastly reply.
Installation Service:
1. We provide detailed CAD drawing to customer for preparing metal structure.
2. We could dispatch our engineer to your place , guide installation and free training.
3. Special designs have special solutions; we will make perfect solutions to satisfy all customers' requirements
