Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Specifications
Membrane Material :
Paper\BOPP\PE\Aluminum Foil
Plastic Film Mulching Modes :
Hot Laminating
Performance :
Waterproof
Max.Coating Speed :
10-150m/Min
Voltage :
220V/380V
Transport Package :
Standard Packaging, Wooden Boxes, Containers or AC
Specification :
customized
Trademark :
Jinxin
Origin :
China
HS Code :
8420100090
Supply Ability :
100sets/Year
After-sales Service :
Video Technical Support, Online Support
Warranty :
1 Year for Machinery Warranty
Classification :
Pre-Coating Laminating Machine
Application :
Packaging Paper
Driven Type :
Electric
Automatic Grade :
Automatic
Customization :
Available | Customized Request
Description

Product Description

Laminating MachineAutomatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Main Features

1.This Non woven fabric laminating machinemaking use of the good adhesive property of polypropylene & polyethylene at melting status machine adheres and aminates Non wovenPaperBOPPPEAluminum foil to Nonwoven fabric,the extruder with helical gear reducer steel adopts automatic temperature-control system to adjust melting temperature, the screw and cylinder are made of alloy steel and done treatment of nitrogenation.

2.The double-die can do single or double-face coating, width of coating & laminating can be regulated, and control coating thickness,laminating speed, automatic edge cutting, edge-blowing, cutting-off and winding devices are applied.

3.This machine has the functions of fully automatic material receiving and refuelling,PLC control system,fully automatic weight control system,man-machine operation interface, and it is a high-quality supply in the same industry.

Technical Parameters
Model JXL-M2400
Extrusion die width 2600mm
Coating width 2000-2400mm
Max.Coating speed 10-150m/min
Coating thickness 0.01-0.1mm
L/d ratio for screw 32:1
Rewinding roll diameter 1200mm
Overall size 15000*12000*6000mm
Total power 150kw
Mirror cool roll diameter 510mm
Adopt material Non wovenPaperBOPPPEAluminum foil

Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown
Automatic Coated Production Line Laminating Machine Jumbo Roll Slitter Rewinder Lamination Machine for gown

FAQ
1. Q:How long will your engineer reach our factory?
A:Within one week after everything ready (machine arrival your factory, non woven material, power source, air compressor etc.All is prepared)

2. Q:How many days will you finish installing?
A:We will finish installation and training within 15 days.

3. Q:What should we charge for your engineer?
A:You should charge for the cost of our engineer's air tickets, hotel, food, and also their salary 100USD one day per person.

4. Q:How long is your machine's warranty period?
A: All our machine have one year guarantee, starting from finished installation.

5. Q:How could you do if the parts broken within warranty?
A: We would express the free replacement parts during the warranty date.

6. Q:Does your engineer understand English?
A:Our engineers understand a little English. All our engineers have more than five years machine installation experience.

7. Q:How do we solve the machine problem after your engineer leaving?
A:Generally speaking, there will be no problem after finishing installation. In case you have any problem, you can contact our sales at any time. Our engineers will take a solution video according your description.
