MTP - LC Multi Cord Mpo Duplex Fiber Optic Patch Cord OM1 -OM4 With Ceramic Ferrule
MTP - LC Multi Cord Mpo Duplex Fiber Optic Patch Cord OM1 -OM4 With Ceramic Ferrule
Specifications
Brand Name :
J&K
Model Number :
MPO Patch cord
Certification :
IS09001-2008.ROHS
Place of Origin :
SHENZHEN,CHINA
MOQ :
50PCS
Price :
Negotiation
Payment Terms :
L/C, T/T
Delivery Time :
3~5days
Packaging Details :
PE bag
Application :
FTTH FTTB FTTX Network
Cable jacket :
PVC/LSZH/Plenum
Operating temperature :
-20℃~+70℃
Name :
fiber optic MPO patchcord
Storage temperature :
-40℃~+85℃
Durability (500 Matings) :
≤0.2dB
Description
OM1 OM2 OM3 OM4 multi cord cable jumpers fiber optic MPO patch cord

Features

  • Ceramic Ferrule;
  • High return loss;
  • Low insertion loss;
  • Good repeat-ability and and ex-changeability;
  • Excellent Polished and 100% tested;
  • Complying with Telcordia ,GR-326-Core, IEC and RoHS Standard.


Applications

  • Local Area Network (LAN)
  • Data communication network
  • Telecommunication optical transmission network
  • Optical access network(OAN)
  • Active device termination
  • Fiber optics data transmission(FODT)


Specifications

Parameter
Model Singlemode Multimode
Polish PC, APC PC
Insertion loss Standard ≤0.7dB ≤0.6dB
Elite low loss ≤0.35dB ≤0.35dB
Return loss PC≥50dB; APC≥60dB ≥30dB
Test wavelength 1310/1550nm 850/1310nm
Durability (500 Matings) ≤0.2dB
Operating temperature -20℃~+70℃
Storage temperature -40℃~+85℃
Fire resistant IEC 60794-2-30
Fiber type OS2, OM1, OM2, OM3, OM4
Cord type 8, 12, 24, 48, 72, 96, 144 cores
Cable diameter 3.0mm (8 or 12 or 24 core), 5.5(24core), or customized
Cable jacket LSZH, OFNR, OFNP
Length(M) 0.3m, 1m, 2m, 5m, 10m, 25m, 50m, 100m
