0.9mm Fiber Optic Cable Lc Connector ,Nickel Plated Brass Lc Duplex Fiber Connector
0.9mm Fiber Optic Cable Lc Connector ,Nickel Plated Brass Lc Duplex Fiber Connector
0.9mm Fiber Optic Cable Lc Connector ,Nickel Plated Brass Lc Duplex Fiber Connector
0.9mm Fiber Optic Cable Lc Connector ,Nickel Plated Brass Lc Duplex Fiber Connector
Specifications
Brand Name :
J&K
Model Number :
DIN SM SX Connector
Certification :
ISO9001:2008
Place of Origin :
SHENZHEN,CHINA
MOQ :
1000PCS
Price :
Negotiation
Payment Terms :
L/C, T/T
Delivery Time :
3~5days
Packaging Details :
PE bag
Product name :
Fiber Optic SC Connector
Application :
FTTH FTTB FTTX Network
Insert loss :
SM≤0.2dB,MM≤0.25dB
Return loss :
PC≥50dB,UPC≥55dB,APC≥65dB
Operating temperature :
-40°C ~ +80°C
Durability :
<0.2db typical change
Description

Fiber Optic Simplex Singlemode DIN Connector with Nickel Plated Brass

Features

  • High quality ceramic components and Material
  • End-face geometry requirement complies to Telcordia GR-326-CORE
  • 100% tested on optical performance (Insertion Loss & Return Loss)
  • Simplex, duplex and higher core densities


Applications

  • Cable Standard Boot (slotted)
  • Fiber Buffer Boot
  • Fiber Boot
  • Cable Short Boot
  • Cable Long Boot (Telcordia type)
  • Fiber Buffer Long Boot (slotted)


Specifications


DIN fiber optical connector
Single mode		 Multimode

Insertion Loss
≤0.20dB
≤0.25dB

≥50 dB (PC)

Return Loss
≥55 dB (UPC)


Durability
≥65 dB (APC)

Operating Temperature		 <0.20 dB typical change 1000 mating
-40 to + 80°C
125.0+1/-0μm, Concentricity: ≤1.0μm 125μm, Concentricity:≤3μm

Ferrule Hole Sizes
125.5+1/-0μm, Concentricity: ≤1.0μm		 144μm, Concentricity: ≤3.0μm
