UPC - DIN 1310 / 1550nm Sc Duplex Fiber Connector For Communication 2.0dB IL
UPC - DIN 1310 / 1550nm Sc Duplex Fiber Connector For Communication 2.0dB IL
UPC - DIN 1310 / 1550nm Sc Duplex Fiber Connector For Communication 2.0dB IL
UPC - DIN 1310 / 1550nm Sc Duplex Fiber Connector For Communication 2.0dB IL
Specifications
Brand Name :
J&K
Model Number :
DIN UPC fiber optical connector
Certification :
ISO9001:2015
Place of Origin :
SHENZHEN,CHINA
MOQ :
1000PCS
Price :
Negotiation
Payment Terms :
L/C, T/T
Delivery Time :
3~5days
Packaging Details :
PE bag
Product name :
Fiber Optic Connector
Application :
FTTH FTTB FTTX Network
Wavelength :
1310~1550nm
Insertion loss :
≤0.2 dB
Return loss :
PC≥50dB,UPC≥55dB,APC≥65dB
Durability :
≤ 0.2db typical change
Description

Communication DIN UPC - DIN UPC high quality 2.0 / 3.0mm DIN fiber optical connector

Features

Content Testing Condition (dB)
SM MM
APC UPC PC
Optical Performance IL(dB) 1310/1550nm LD Light 0.2 0.2 0.2 0.2
RL(dB) 1310/1550nm LD Light 65 55 50 35

Environment

Performance

 High Temperature +85℃,168H 0.2
Temperature cycle -40~+75℃,21cycle,168H 0.2
Humidity thermal(Fixed) 5℃,95%R.H.,168H 0.2
Humidity thermal cycle 10~+65℃,95%R.H.,21 cycle,168H 0.2
Mechanical Performance Vibration 10~55Hz,1.5mm(p-p) 0.1
Bending 0.9kgf,-90°~+90°,100cycle 0.1
Torsion 2.5kgf,10times/min,±180°,200times 0.1n
Anti-tension 90N,10min 0.1
Dropping 1.5 height, 8 times 0.2
Repeat 10 Times inserts 0.1
Durability >1000times 0.2

Mechanical Performance and Working temperature

Content Character Unit
Working Temperature -40~+85 ℃
Storage Temperature -5~+50 ℃

Φ3.0 Fibre Curl Radius

 >30 mm
Φ3.0 Anti-Tensile Strength >9.0 Kgf
Main Mechanical Size SEE LAYOUT -

3D Index

Type

Content

 APC UPC LC
Radius of Cury(mm) 5-12 10-25 7-25
Apexoffset(um) 0~+50
FiberHeight(nm) -50~+50
Angle(deg) 7.5~8.5 /

/

UPC - DIN 1310 / 1550nm Sc Duplex Fiber Connector For Communication 2.0dB IL

UPC - DIN 1310 / 1550nm Sc Duplex Fiber Connector For Communication 2.0dB IL
