DIN Single Mode Fiber Lc Connector , Circular Fiber Optic Quick Connector For FTTH Network
DIN Single Mode Fiber Lc Connector , Circular Fiber Optic Quick Connector For FTTH Network
Specifications
Brand Name :
J&K
Model Number :
DIN SM Fiber Optic Connector
Certification :
ISO9001:2015
Place of Origin :
SHENZHEN,CHINA
MOQ :
1000PCS
Price :
Negotiation
Payment Terms :
L/C, T/T
Delivery Time :
3~5days
Packaging Details :
PE bag
Product name :
Fiber Optic Connector
Application :
FTTH FTTB FTTX Network
Durability :
≤ 0.2db typical change
Operating temperature :
-20~70℃
Storage Temperature :
-40~85℃
Return loss :
UPC≥50.0dB,APC≥60.0dB
Description

DIN singlemode Fiber Optic Connector for FTTH Network

Features

  • Corrosion resistant body
  • Boots in a variety of colors
  • Free-floating ceramic ferrule
  • Low insertion loss and back reflection loss


Applications

  • Local Area Networks (LANs)
  • Data processing networks
  • Test equipment
  • Premise installations
  • Wide Area Networks (WANs)


Specifications


ITEM		 PARAMETER
Applicative Connector Type SC,LC,FC,ST,MU,D4,DIN
Fiber mode Single mode Multi-mode
Test wavelength 1310nm, 1550nm 850nm, 1300nm
Insertion Loss typical≤0.20dB,Max≤0.30dB typical≤0.15dB,Max≤0.25dB
Return Loss UPC≥50.0dB,APC≥60.0dB ≥35.0dB
Durability ≤0.20dB typical change,1000 mating
Applicative cable OD. ∮0.9mm/∮1.8mm&∮2.0mm /∮3.0mm (MU only ∮0.9mm/∮2.0mm)
Connector Ferrule OD. ∮2.5mm:SC, FC,ST,DIN; ∮2.0mm:D4; ∮1.25mm:LC,MU
Angle BOOT SC,LC(45 or 90 degree)
Operating Temperature -20ºC to +70ºC
Storage Temperature - 40ºC to +85ºC
Ferrule Specification 125.3+1/-0μm, Concentricity: ≤1.0μm 127+3/-0μm, Concentricity: ≤3.0μm

DIN Single Mode Fiber Lc Connector , Circular Fiber Optic Quick Connector For FTTH NetworkDIN Single Mode Fiber Lc Connector , Circular Fiber Optic Quick Connector For FTTH Network
