stepper motor closed loop control 3m Encoder Motor Cable Closed Loop Stepper Motor Driver High Torque 1.89N.M
stepper motor closed loop control 3m Encoder Motor Cable Closed Loop Stepper Motor Driver High Torque 1.89N.M
stepper motor closed loop control 3m Encoder Motor Cable Closed Loop Stepper Motor Driver High Torque 1.89N.M
stepper motor closed loop control 3m Encoder Motor Cable Closed Loop Stepper Motor Driver High Torque 1.89N.M
Specifications
Brand Name :
Jkongmotor
Model Number :
NEMA23 JK57HS-BFED
Certification :
CE, ROHS,ISO9001
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
3-10pcs
Price :
US$58~US$79
Payment Terms :
T/T , paypal , Western Union, L/C
Supply Ability :
100000pcs/month
Delivery Time :
For samples , 7-15 days / For batch , 15-25days
Packaging Details :
with export carton . big quantity with pallet
Shaft :
Single
Leads :
4
Current :
4.2A
Holding Torque :
1.89N.m
Weight :
2.3KG
Step Angle :
1.8°
Description


Closed Loop Stepper Motor High Torque 1.89N.m & Driver & 3m Motor Cable & 3m Encoder Cable

stepper motor closed loop control 3m Encoder Motor Cable Closed Loop Stepper Motor Driver High Torque 1.89N.M


Genaral Specification of stepper motor closed loop control:

Item Specifications
Step Angle 1.8°
Temperature Rise 80℃max
Ambient Temperature -20℃~+50℃
Insulation Resistance 100 MΩ Min. ,500VDC
Dielectric Strength 500VAC for 1minute
Shaft Radial Play 0.02Max. (450g-load)
Shaft Axial Play 0.08Max. (450g-load)
Max. radial force 75N (20mm from the flange)
Max. axial force 15N


Electrical Specification of closed loop stepper motor:

Model No.

Step Angle

Motor Length

Current

/Phase

Resistance

/Phase

Inductance

/Phase

Holding Torque

# of Leads

Detent Torque

Rotor Inertia

Mass
( °) (L)mm A Ω mH N.m No. g.cm g.cm Kg
JK57HS76-4204 BFED-0.35M 1.8 76 4.2 0.6 1.8 1.8 4 600 440 1.1

Driver Specification:

stepper motor closed loop control 3m Encoder Motor Cable Closed Loop Stepper Motor Driver High Torque 1.89N.M

Nema 34 Closed Loop Stepper Motor S High Torque 4.5N.M With Encoder Driver / Cables
Step and direction control
Closed position loop for no loss of movement synchronization
Operating voltage: 20-80 VDC
Load based output current of 0.1 - 10 A
High torque at starting and low speed
No torque reservation
High stiffness at standstill
Significantly reduced motor heating
Smooth motor movement and extra low motor noise
Quick response, no delay and zero settling time
No loss of steps; no hunting; no overshooting
Plug-and-play and no tuning


Our service:


We do also manufacture other products,such as stepper motor;stepper motor with gearbox.
linear stepper motor,closed loop stepper motor,stepper motor with brake,stepper motor sriver;
brushless dc motor;bldc motor with gearbox,bldc motor driver;
brush dc motor,spindle motor,ac servo motor kit,couplings,pulley,power supply and so on.
