Specifications
Brand Name :
JK
Model Number :
JK86BLS98
Certification :
CE,ROHS,ISO
Place of Origin :
Jiangsu, China
MOQ :
3-10pcs
Price :
US$38.93~US$47.91
Payment Terms :
T/T , paypal , Western Union, L/C,
Supply Ability :
100000pcs/month
Delivery Time :
For samples , 7-15 days / For batch , 15-25days
Packaging Details :
with export carton . big quantity with pallet
Name :
86mm Electric brushless motor with hall sensor
Voltage :
24V/36V/48V
Power :
110w/220w/330w/440w/660w
Speed :
3000rpm/4000rpm/5000rpm/6000rmp
Sensor :
Honeywell
Spare :
brushless dc motor controller/driver
High Light: :
3000rpm brushless dc motor 86mm, brushless dc motor 86mm 4.2NM, 48v 400w bldc motor
MOQ :
10pcs
Description

Industrial 86mm Brushless Dc Motor Flange 440W 48Vdc 3000rpm

Changzhou Jkongmortor Co. Ltd. is located in Changzhou city, Jiangsu province, China. We are a comprehensive company which specializes in producing and researching motors and drivers. Our main products include hybrid step motor, and step driver, step servo motor and driver, integrated step servo motor, linear stepper motor, geared stepper motor, stepper motor with brake, brushless dc motor. And we are always researching and developing new products.

our main products:

hybrid stepper motor and drives

Brushless DC motor and drives

planetary gearbox

AC servo motor

Spindle motor

Linear guide and its pairs

Ball screw and its pairs

  • General specification:

    Item Specification
    Widing type Star/Delta
    Hall effect angle 120 degree electrice angle
    Shaft runout 0.025mm
    Radial play 0.02mm/50g
    End play 0.08mm/50g
    Max radial force 220N/20mm from the flange
    Max axial force 60N
    Insulation class Class B
    IP class IP 40
    Dielectric strength 500VDC for one minute
    Insulation Resistance 100MΩmin 500VDC

  • Electrical Specification:

    Model Rated Voltage(VDC) Rated Current(A) Rated Power(W) Rated Torque(N.m) Peak Torque(N.m) Rated Speed(rpm) Length(mm) Mass(kg)
    JK86BLS58 48 3 110 0.35 1.05 3000 71 1.5
    JK86BLS71 48 6 220 0.7 2.1 3000 90 1.8
    JK86BLS84 48 9 330 1.05 3.15 3000 98 2.3
    JK86BLS98 48 12 440 1.4 4.2 3000 117 2.4
    JK86BLS125 48 18 660 2.1 6.3 3000 144 3.8

    Electrical Connection:

    Lead No. Lead Color Lead Gauge Function Description
    1 Red UL3266/28AWG VCC+5VDC SUPPLY VOLTAGE FOR HALL SENSORS
    2 Black GND GROUND FOR HALL SENSORS
    3 Yellow HALL A SIGNAL OF HALL A
    4 Green HALL B SIGNAL OF HALL B
    5 Blue UL3266/20AWG HALL C SIGNAL OF HALL C
    1 Yellow PHASE U MOTOR PHASE U
    2 Green PHASE V MOTOR PHASE V
    3 Blue PHASE W MOTOR PHASE W
