Flameproof 600 G/M2 Silicone Coated Fiberglass Fabric For Heat Insulation
Flameproof 600 G/M2 Silicone Coated Fiberglass Fabric For Heat Insulation
Flameproof 600 G/M2 Silicone Coated Fiberglass Fabric For Heat Insulation
Flameproof 600 G/M2 Silicone Coated Fiberglass Fabric For Heat Insulation
Flameproof 600 G/M2 Silicone Coated Fiberglass Fabric For Heat Insulation
Flameproof 600 G/M2 Silicone Coated Fiberglass Fabric For Heat Insulation
Specifications
Brand Name :
Jiangnan
Model Number :
Silicone Coated Glass Cloth Heat Resistant Double Sides
Certification :
ISO 9001 2015
Place of Origin :
CHINA
MOQ :
Quantity: 500 Square Meters or Negotiation
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30000 square meters per day
Delivery Time :
15 Working days after payment
Packaging Details :
Each Roll in a Carton Box, 20 Cartons/Pallet
Product name :
Silicone Coated Glass Cloth Heat Resistant Double Sides
Coating :
silicone coated glass cloth
Working Temperature :
-70-260Degree
Breaking Voltage :
20-50KV/MM
Good Feature :
Waterproof
Application :
Wall/Roof Covering Cloth
Material :
Silicone + Fiberglass + Fabric
Description

Flameproof 600 g/m2 Silicone Coated Fiberglass Fabric for Heat Insulation

1. Description:

What is silicone coating fiberglass cloth?

There is a wide range of silicone fiberglass fabric with a weight from 120 to 1400 g/sq.m. with a width up to 2 m with different types of finish improving their properties. One of the considerable sectors of silicone fiberglass fabric application — production of welding blankets, fire protective blankets, screens and curtains, casing as a thermal barrier for protection of the equipment, high-temperature insulation of furnaces, turbines, screens for protection from molten metal splashes, sparks, thermal insulation.
7628,3732,3784 and any other kinds of basic fiberglass fabric are used for Silicone coated fiberglass cloth. These fabrics exhibit the strength and tear resistance of fiberglass, as well as, provide excellent release properties.

Total weight 530 g/m2
Thickness 0.4 mm
Color Black
Fire resistance Yes
Working temperature -500C to +2600C
Coating Silicone Coated On 1 Side.
Standard widths 1000mm, 1270mm, 1550mm,2000mm(MAX)

2. Technique Data Sheet

Style 3732 Silicone Coated Cloth
1 Weave 4 HS Satin
2 Yarn Warp EC9 136 1×2
(tex) Weft EC9 136 1×2
3 Width 101.6 cm
152.4 cm
4 Fabric Thickness 0.4 mm
5 Coating Two Sides – Silicone Rubber (100 g)
6 Coating Thickness 0.1 mm
7 Overall Thickness 0.4 mm
8 Overall Weight 530 g/m2
9 Thread Count Warp 18 per cm
Weft 13 per cm
10 Tensile Strength Min. Warp 8000 N/5cm
Weft 6000 N/5cm
11 Temperature Max. 260oC

3. Much More Related Products

How to choose Knife Coating Silicone Coating fiberglass fabric?

Knife Coating Silicone Coating Differences between Premier and Industrial Quality
Premier Quality Industrial Quality
1 Loomstate High-speed Rapier Weaving Machine Normal Dornier (small weaving defects might occur occasionally)
2 Silicone Wet, High-Quality Silicone Rubber Dry, Standard Silicone Rubber
3 Appearance Shiny and Tacky Dull but Smooth
4 Performance Strong Adhesion Strength Between Silicone Fabric, High Abrasion Resistance Normal Adhesion Strength Between Silicone Fabric, Normal Abrasion Resistance, silicone might be peeled or scratched off in some particular circumstances
5 Application Mostly for Removable Insulation Jackets Mostly for Welding, But Also for Economic Removable Insulation Jackets

Premier Quality Thickness (mm) Weight (g/m2) Weaving
E7628-LG1 0.2mm 230 Plain
E7628-LG2 0.23mm 280 Plain
E3732-LG1 0.4mm 510 Twill
E3732-LG2 0.45mm 590 Twill
E666-LG1 0.6mm 750 Stain
E666-LG1 0.7mm 850 Satin
E3784-LG1 0.8mm 950 Satin
E3784-LG2 0.9mm 1050 Satin
Other Thickness and Weight can be Customized

Industrial Quality Thickness (mm) Weight (g/m2) Weaving
E7628-SG1 0.2mm 230 Plain
E7628-SG2 0.23mm 280 Plain
E3732-SG1 0.4mm 510 Twill
E3732-SG2 0.45mm 590 Twill
E666-SG1 0.6mm 750 Stain
E666-SG1 0.7mm 850 Satin
E3784-SG1 0.8mm 950 Satin
E3784-SG2 0.9mm 1050 Satin
Other Thickness and Weight can be Customized

4. Silicone Coating Cloth Features
Silicone rubber-coated fiberglass fabrics are used to protect hydraulic hoses, lines, wires, and cables from heat, flame, molten metal spatter, slag, welding spatter, grinding sparks, pollution, ozone, UV rays, and abrasion. Made of fiberglass base cloth, plus a layer of high-temperature silicone rubber protection. High temperature and heat resistance.

5. Application

Welding & Burning Safety Blankets & Curtains
Furnace High-Temperature Insulation

Flange & Valve Covers
Furnace Curtains
High-Temperature Composites
Thermocouple Insulation
Fuel line insulation
Stress Relieving Insulation

6. More Images for Coated Fiberglass Cloth

Flameproof 600 G/M2 Silicone Coated Fiberglass Fabric For Heat Insulation

Flameproof 600 G/M2 Silicone Coated Fiberglass Fabric For Heat Insulation
