Jnicon LED Waterproof Power Connector , Waterproof M15 Connector 4 Way Parallel
Jnicon LED Waterproof Power Connector , Waterproof M15 Connector 4 Way Parallel
Specifications
Brand Name :
Jnicon
Model Number :
Waterproof Power Connectors
Certification :
TUV/ UL/ CQC / CE / ROHS
Place of Origin :
China
MOQ :
100 (10 Pairs of samples)
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000/days
Delivery Time :
3-5 working days
Packaging Details :
1.Plastic bag;2.Carton;3.As per customer's requirements
product details :
2 Pin Outdoor Waterproof Power Connector
number of Pin :
2 pin
Contact material :
Copper alloy (Gold-plated)
Current rating :
10A
voltage rating :
300V
Waterproof level :
IP68
Description

4 Way Parallel Waterproof Power Connector , Jnicon 2 Pin M15 Waterproof Connector

Description of Jnicon 2 Pin M15 Waterproof connector

M15 waterproof connectors is in common use for led street lighting, its the CSA starndard connectors in China.Popular to all the lighting application, this thread locking connectors could support IP68 outdoor using, no matter for dimming lights, landscape lighting or floor lighting,even its is widely used in many others underwater tight request application.

Main Feature

  • Parallel & Series circular available
  • Different cable size and length welcome
  • 2PIN 3 PIN could be support in F connector
  • Outputs quanity could be different in 2 way,3way to many connection model
  • IP68 waterproof connectors
  • Male female connector
  • Waterproof LED connector

Operation Parameters
Voltage Rating 500VAC max
Current Rating 10A max
Min Wire Size OD 3.0mm ~ 6.0mm
Max Wire Size OD 6.5mm ~ 9.0mm
Max.Cable Cross Section Area 0.3mm2 ~ 1.5mm2

Technical Parameters
Contact Resistance 10 mΩ max
Insulation Structure 500 MΩ at 500VDC
Operating Temperature -40°C ~ +105°C
IP Class IP67 (1m / 30min)
Mold Material PA66
Contact/Terminal Material Gold Plated Brass
Seal Material Silicone

Electrical Parameters
Number of Poles 2pin 3pin
Current Rating 10A max
Voltage Rating 500VAC max
Durability Voltage 1500VAC @ 60 s.

FAQ

1. Q: Are you a factory or trading company?
A: We are a factory. Located in Jnicon Industrial Park, Bao'an District,Shenzhen,China
2. Q: How to buy your products?
A: You need to do as followings:
* Confirm Current Rating and Number of Contacts
* Confirm Assembly style
* Confirm Cable Wire guage
* Confirm Cable Length and Material.
3. Q: How can I get samples?
A: It's my honor to offer you samples,and the freight should be paied by yourself.You can let me know your courier number and your detail address,Then I can send you sample at once.
