Ss 304 Wedge Wire Screen Filter For Wastewater Treatment
Ss 304 Wedge Wire Screen Filter For Wastewater Treatment
Ss 304 Wedge Wire Screen Filter For Wastewater Treatment
Ss 304 Wedge Wire Screen Filter For Wastewater Treatment
Ss 304 Wedge Wire Screen Filter For Wastewater Treatment
Ss 304 Wedge Wire Screen Filter For Wastewater Treatment
Ss 304 Wedge Wire Screen Filter For Wastewater Treatment
Ss 304 Wedge Wire Screen Filter For Wastewater Treatment
Ss 304 Wedge Wire Screen Filter For Wastewater Treatment
Ss 304 Wedge Wire Screen Filter For Wastewater Treatment
Ss 304 Wedge Wire Screen Filter For Wastewater Treatment
Ss 304 Wedge Wire Screen Filter For Wastewater Treatment
Ss 304 Wedge Wire Screen Filter For Wastewater Treatment
Ss 304 Wedge Wire Screen Filter For Wastewater Treatment
Specifications
Brand Name :
Hengyuan
Model Number :
102913
Certification :
ISO, CIQ, CO, FORM E
Place of Origin :
HENGSHUI
MOQ :
1 piece
Price :
USD 20/meter
Payment Terms :
T/T,L/C,
Supply Ability :
500m2/ day
Delivery Time :
7 workdays
Packaging Details :
Wooden box
Name :
Johnson Wedge wire screen filters
Material :
Stainless Steel 304, 316L, Duplex steel 2205,2507 etc.
OD :
25-1500mm
Length :
upto 6m
Slot Size :
25um-1000um
Wire size :
0.75*1.5mm,1*2mm, 1.2*2mm etc.
Support rod :
2*3mm, 3*5mm etc
Ends :
Flange, welded rings, male/female etc.
Shape :
Round, Rectangular, Square, Arc, Etc.
Surface Treatment :
Polish, Electro-polish, Anodizing, Sandblasting, Etc.
Structure :
Wedge Wire Mesh, Welded Wedge Wire Mesh, Wedge Wire Screen, Wedge Wire Filter, Etc.
Port :
Tianjin,Shanghai, Etc.
Description

vietwater 2023 h05 johnson wedge wire screen filters

Johnson wedge wire screen filter Description:

Johnson Wedge wire screen filter is a kind of metal mesh product made of stainless steel and other materials. It is widely used in many industries and applications, such as filtration, separation, architectural mesh, and other industrial and residential applications. It is made of a series of individual wires that are welded together in a series of interlocking patterns. The individual wires are welded together in a V-shaped pattern, creating a durable and strong mesh. The slot size of the wedge wire mesh ranges from 0.1mm to 10mm, and the surface treatment can be polish, electro-polish, anodizing, sandblasting, etc. The width and length of the wedge wire mesh can reach up to 4m, and the port includes Shanghai, Ningbo, etc. This multi-purpose SS wedge wire screen pipe can be used as wedge wire filter in many different applications.

Johnson wedge wire screen filter Features:

  • Product Name: Johnson Wedge Wire Screen Filter
  • Features: High Strength, Corrosion Resistance, Long Service Life, etc.
  • Width: 4m
  • Name: Wedge Wire Screen Pipe
  • Port: Shanghai, Ningbo, etc.
  • Structure: Wedge Wire Mesh, Welded Wedge Wire Mesh, Wedge Wire Screen, Wedge Wire Filter, etc.
  • Special Focus: Johnson wedge wire screen, Wedge wire screen pipe, Johnson wire screen

Johnson wedge wire screen filter Technical Parameters:

Parameter Value
Width 4m
Length 4m
Structure Welded Wedge Wire Mesh, Wedge Wire Screen, Wedge Wire Filter, Etc.
Material Stainless Steel
Features High Strength, Corrosion Resistance, Long Service Life, Etc.
Wire Diameter 1.0mm-3.2mm
Shape Round, Rectangular, Square, Arc, Etc.
Slot Size 0.1mm-10mm
Surface Treatment Polish, Electro-polish, Anodizing, Sandblasting, Etc.
Package Wooden Case, Pallet, Etc.
Keywords Wound Screen Pipe, Wedge Wire Screen Tube, Vee-Shaped Wire Screen Tube, Wedge Shaped Wire Screen Tube, Wedge Wire Filter Tube, Wedge Wire Cylinder, Wedge Wire Filter, Wedge Wire Strainer, Wedge Wire Filter Element, Wedge Wire Screen Element, Wedge Wire Flat Panel, Wedge Wire Screen Panel, Wedge Wire Mesh, Wedge Wire Screen Mesh, Wedge Wire Filter Mesh

Johnson wedge wire screen filter Customization:

Johnson Wedge Wire Screen Filter
  • Brand Name: Hengyuan
  • Model Number: 102913
  • Place of Origin: HENGSHUI
  • Certification: ISO, CIQ, CO, FORM E
  • Minimum Order Quantity: 1 piece
  • Price: USD 20/meter
  • Packaging Details: Wooden box
  • Delivery Time: 7 workdays
  • Payment Terms: T/T,L/C
  • Supply Ability: 500m2/ day
  • Material: Stainless Steel
  • Features: High Strength, Corrosion Resistance, Long Service Life, Etc.
  • Slot Size: 0.1mm-10mm
  • Shape: Round, Rectangular, Square, Arc, Etc.
  • Wire Diameter: 1.0mm-3.2mm

Wedge wire mesh, Wedge wire screen, Wedge wire screen tube, Wedge wire filter are customized services provided by Hengyuan. We have high quality and corrosion-resistant wedge wire screen, wedge wire screen tube and wedge wire filter with good strength, long service life and competitive price.

Johnson wedge wire screen filter Packing and Shipping:

  • The Johnson Wedge Wire Filter will be securely packaged in wooden crates.
  • The crates will be strapped with steel bands.
  • The Johnson Wedge Wire Filter will be shipped by a reputable shipping company.
  • Shipping type:By sea, By air, or by express (DHL, FedEx etc.)
