Vee-Shaped Wire Johnson Wire Wrapped Screen Used In Water And Oil Wells
Vee-Shaped Wire Johnson Wire Wrapped Screen Used In Water And Oil Wells
Vee-Shaped Wire Johnson Wire Wrapped Screen Used In Water And Oil Wells
Vee-Shaped Wire Johnson Wire Wrapped Screen Used In Water And Oil Wells
Vee-Shaped Wire Johnson Wire Wrapped Screen Used In Water And Oil Wells
Vee-Shaped Wire Johnson Wire Wrapped Screen Used In Water And Oil Wells
Vee-Shaped Wire Johnson Wire Wrapped Screen Used In Water And Oil Wells
Vee-Shaped Wire Johnson Wire Wrapped Screen Used In Water And Oil Wells
Specifications
Brand Name :
HengYuan
Model Number :
HY0222010
Certification :
ISO, CIQ, CQ
Place of Origin :
Hebei,China
MOQ :
10 pcs
Price :
230usd/pc
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
2000 pcs /month
Delivery Time :
7 days
Packaging Details :
wooden boxes or customized
Name :
Vee-Shaped Wire Johnson Wire Wrapped Screen
Brand name :
HengYuan
Material :
Stainless Steel 304, 316L, Duplex steel 2205,2507 etc.
Diameter :
4" 6" 8" 10" 12" 14" 16"
Technique :
welding
Feature :
non-clogging,anti-corrosion
Application :
oil/gas/liquid filtration
Slot :
0.5mm 0.63mm 0.75mm 1.0mm etc
Description

Vee-shaped Wire Johnson Wire Wrapped Screen From China Supplier

The world's most advanced full wound welding process in the world is adopted by the wrapped wire screen. The special stainless steel trapezoid (wedge-shaped) wire winding is welded on a group of longitudinal support rods arranged in a round arrangement, thus ensuring its strength and service life.

Due to the adoption of full program welding, not only the strict integrity of the product is ensured, but also the ideal gap size is formed. Compared with the commonly used welding technology in China, the full welded wedged wire winding screen tube, filter pipe, water cap, water distributor, resin trap and sieve plate have the characteristics of smooth tube surface, no production edge angle, no burr, uniform gap and no grease leakage.

The wedge-shaped wire screen is widely used in oil, gas and water wells for sand prevention and its application in chemical industry, environmental protection, and other industries. It is the most widely used filter screen in all kinds of oil, water resources recycling, and resin collection.

Material stainless steel wire 304,302,304L,316,316L or galvanized steel wire
OD 1 Iinch,3 inch,4 inch,6inch,8 inch,10 inch,12 inch,14 inch,16 inch,18 inch,20 inch
the slot 0.1mm-45mm
the wire 2.0mm*3.0mm ,3.0mm*4.6mm,3.0mm*5.0mm
the rods 3.8mm/22,3.8mm/32,3.8mm/48,3.8mm/50
Styles of connection welding ring,threaded male /female coupling
Standard length 1000mm-5850mm
