Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Specifications
Type :
Gluing Machine
Applicable Industries :
Manufacturing Plant, Construction works
Showroom Location :
None
Video outgoing-inspection :
Provided
Machinery Test Report :
Not Available
Marketing Type :
New Product
Warranty of core components :
1 Year
Core Components :
Motor
Condition :
New
Application :
APPAREL, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, JR-810A 10L Hot melt glue machine
Packaging Type :
case
Packaging Material :
Wood
Automatic Grade :
Semi-automatic
Driven Type :
Electric
Voltage :
220V, 220V
Place of Origin :
Fujian, China
Brand Name :
JORI
Dimension(L*W*H) :
950x750x1280
Weight :
180 KG
Warranty :
1 Year
Key Selling Points :
Easy to Operate
After-sales Service Provided :
Engineers available to service machinery overseas
Product name :
Hot melt glue machine glue gun for packing
Max operation TEMP :
250℃
Tank Capacity :
50L
Max.melting rate :
50 kg/hour
Color :
Blue ( can be customzied)
Max.cps :
20000CPS
Packaging Details :
Wooden Cases, Seaworthy Package.
JORI 50L Hot Melt Glue Machine
Port :
Xiamen Port, China
Supply Ability :
10000 Unit/Units per Month JORI 50L Hot Melt Glue Machine
Price :
$6,600.00/Units 1-1 Units
Description
Products Description

JORI 50L HOT MELT GLUE MACHINE

JORI Group CO.,Limited supply all kinds of the Hot melt compatible parts for hot melt glue machines. Consumable parts like Nozzles, Hoses, Single & Multi module guns, Modules, Cordsets, heaters & Solenoid valves etc. We can provide complete gluing solutions for Food, Pharma,Beverages,Cosmetics, Non Woven,Non Food consumer Products,Seeds,Cable,Book binding & many more sectors.We can give solutions for Cart on, Labeling,Leaflet attachment,Tray formation,Straw application etc applications

Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Features:
1.The use of Huibang brand temperature control system, reliable and stable quality, heating components and temperature sensors are imported brands, temperature control can be accurate to plus or minus 0.1 degrees Celsius, hot melt adhesive is uniform heat, no discoloration, no carbonation, The original hot melt is good chemical and physical properties. 2. Progressive preheating cylinder design, first into the first melt, coated with imported DuPont Teflon anti-stick coating, low energy consumption, reduce the phenomenon of plastic carbonization, to maintain the best quality of plastic. 3. Insulation standby function, according to the actual production requirements set insulation temperature, to prevent plastic carbonization, reduce power consumption, shorten the shift or noon heating time. 4. With temperature over-temperature alarm power protection, over-temperature 1-50 degrees can be adjusted freely, when the actual temperature exceeds the set value, the machine automatically turn off the power supply automatically. Using imported motor and Yatai inverter, electrical components are imported joint venture brands. 5. According to customer demand external timer switch function, that is, 7 days time control function, according to the workers every day to set the machine to run automatically and off. 6. The use of double 100 mesh filter, reducing the phenomenon of nozzle clogging, a new type of directional return device, pressure adjustment more accurate and stable, the use of the latest precision melting of molten steel, warranty for ten years. 7. Frame-type shell design, sheet metal from the import of CNC laser cutting machine processing, the whole sheet metal parts assembly more sophisticated and beautiful, and easy maintenance and maintenance. 8. The use of high-precision imported gear pump, glue pressure output stability, the use of imported high-speed steel heat treatment manufacturing, extending the life of the pump, free warranty for 2 years, greatly reducing the customer's maintenance costs and improve production efficiency. 9. Inverter voltage protection function, when the actual temperature of the tank does not reach the set temperature value, (motor) motor does not work, play a protective role, to extend the service life of equipment and to avoid illegal employees to the enterprise economic losses. 10. With the EU standard circuit design, with automatic leakage protection function, the whole device is more secure, voltage detection, voltage overvoltage, current overcurrent protection, to prevent the voltage is too high and damage the equipment system. With current and voltage protection and other functions.
Specifications:
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Tank Capacity
50kg
Max .melting rate
50kg/hour
Max. Operation temp.
0-400℃
Total Power
11000Watt
Machine Dimension(L*W*H)
980*700*1280mm
Max. Viscosity
20000pcs
Hose Output
1-4 lines
Power Requirement
220V 50HZ Single Phase
Motor
400W
Weight
180kg
Tank Dimension(L*W*H)
300*280*600mm
Gear Pump
20CC
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment

Connect With Manual Glue Gun

Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment

Connect with Slot Die Gun and Fiber Gun

Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment

About the Main Accessories (Module):

Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Application
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Related Products
Why Choose Us
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
Package & Shipping
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
FAQ
Horizontal Type Gear Pump Fifty Liter Hot Melt Glue Equipment
1. How long is your Warranty?
A: All our products will have ONE year guarantee and we will continue to offer advice and spare parts after this period.
Within ONE year after receiving our machines, Under right operation and non-artificial reasons, If there are any damaged parts or accessories, We will replace them by air-mail or Express immediately FREE OF CHARGE.
After ONE year warranty, Spare parts and damaged parts will be charged at cost price. If there is something wrong with the machine, We are responsible to solve this problem soonest, and help customers to restore production as soon as possible.

2. How to Guarantee transaction security?
A: We could draft Trade Assurance order for buyers via Alibaba-Trade Assurance is a free service by Alibaba.com that’s designed to help create trust between buyers and suppliers. Trade Assurance helps buyers in the event of shipping and quality-related dispute.

3. Do your company accept Alibaba Trade Assurance?
A: yes, of course. （1） We will draft order according buyer requirements. （2）Negotiate terms with the supplier
and confirm order （3） Make payment to the bank account designated by Alibaba.com

4. What's the payment terms?
A: 30% initial payment when place your order, 70% balance payment before shipment.

5. About machine's Transportation & documents?
A: Pls advise us the nearest port of your city in order to check the latest sea freight for you at first. Fast and security
shipping company will be chose by our Delivery Department for customers (if we signed contract under CIF term). Even All risks Insurance will be covered during the whole transportation.
