Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation
Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation
Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation
Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation
Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation
Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation
Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation
Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation
Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation
Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation
Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation
Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation
Specifications
Brand Name :
JOYSHING
Model Number :
Vacuum Glass JY-IV111
Certification :
CE,ISO, CSi,SGCC
Place of Origin :
CHINA
MOQ :
1 wooden box
Price :
Usd/1-999/sqm
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
3000sqm/day
Delivery Time :
1-2weeks
Packaging Details :
Wooden box
Name :
Vacuum Glass Window
Model :
JY-IV111
Size :
1000mm*1200mm
Glass thickness :
12.3mm
Vacuum Layer Width :
0.3mm
Structure :
6TL+0.3V+6T
Glass Color :
Gery,green,extra clear,etc.
Free samples available :
Sea Worthy Strong Wooden Crates
Advantage :
Light and thin,Insulation ,Noise reduction
Lead time :
15 working days
Description

Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti-condensation

Vacuum glass is a new type of energy-saving glass. The structure of vacuum glass is similar to insulating glass, the difference is that the gas in the cavity of vacuum glass is very thin, almost close to vacuum. Compared with normal glass, vacuum glass is lighter, thinner and has better thermal insulation effect. There is no gas inside the vacuum glass, so there will be no "internal condensation and fogging".The service life of Jiaxing vacuum glass can be as long as 25 years.

Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation

The structure of vacuum glass

Vacuum glass seals the surroundings of two pieces of flat glass, evacuates the gap and seals the exhaust holes. The minimum gap between the two pieces of glass is 0.3mm. In order to achieve better heat insulation performance, one of the glass uses Low-E Glass

Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation

Specification

Product name
Vacuum Glass Window
Model
JY-IV111
Structure
6TL+0.3V+6T
Glass thickness
12.3mm
Size
1000mm*1200mm
custom
Vacuum Layer Width
0.3mm
Lead time

15 working days
Warranty
25 years
Samples

Free samples available

Payment Terms

30% deposit, and balance before shipment by T/T

Model Low-E vacuum glass Thickness Visible Light Solar Energy NFRC 100-2010 LSG

Weighted sound insulation

dB
Transmittance % Reflectivity% Transmittance % Reflectivity% U Value W/m²· K SHGC Shading Coefficient
Ext. Int. Winter Nighttime Summer Daytime
JY-IV111 6TL+0.3V+6T 12.3mm 84.1 11.9 11 46 31 0.5 0.6 0.36 0.52 1.39 45


Above data are for reference only. parameters for a specific product needs to be calculated separately.
For parameters related to a specific product. please refer to the data provided by Joy Shing Glass.

Product photo

Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation

Application Fields Of Vacuum Glass

Building

Window

Curtain Wal

Door

Greenhouse etc.

Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation

Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation
Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation
Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti CondensationVacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti CondensationVacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation
Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation
Vacuum Glass Window 6TL+0.3V+6T LOW-E Tempered Vacuum Glass Anti Condensation
FAQ
Q: What is the MOQ?
A: Generally, there is no MOQ for processed glass, but if you want to receive the best price, the bigger quantity, the better price.
Q: Can I have a small sample to verify the quality?
A: Sure, we welcome samples to be tested and checked for quality.
Q: Can I visit your factory?
A: Yes, we welcome all of the customers to visit our factory when you have real requirements, we will take you to each of our production lines, and discuss orders in our office.
Q: Do you offer a guarantee for the products?
A: Yes, generally, we offer 10 years warranty for processing glass based on your normal uses, we advise you use it in the right way can keep your product's service life a long time .
Q: How do you control the quality of your products?
A: We have standard management in the factory based on the ISO system, and train our staff regularly, our production department will choose high-quality materials for glass strictly, for finished excellent products. And we have QC for each process, once find any problem, we will replace the glass, to make sure every piece of glass go to the customer's warehouse is in good condition.
