OEM Industrial Laser Range Finder Module , RS232 B605B Laser Distance Meter Module
OEM Industrial Laser Range Finder Module , RS232 B605B Laser Distance Meter Module
Specifications
Brand Name :
JRT
Model Number :
B605B
Certification :
CE ,ISO9001,ROHS, FCC ,FDA.
Place of Origin :
Chengdu China
MOQ :
1
Price :
Welcome to contact us for discussion
Payment Terms :
T/T, Western Union, Pay pal
Supply Ability :
10000 pcs/day
Delivery Time :
1-3 working days
Packaging Details :
neutro-packing
PRODUCT NAME :
OEM Industrial Laser Distance Sensor with RS232
ACCURACY :
+-1mm
size :
72*40*18mm
Weight :
About 25g
Measuring Range :
0.03-150m
Voltage :
DC3.0V
Description

OEM Industrial Laser Distance Sensor Range Finder Module with RS232 B605B

Description:

This module can be secondary development, which support TTL level and CMOS.Industrial Laser Distance Sensor 150m can be widely used in professional surveying, mapping, construction, robots, hunting arrows, industrial monitoring and automated measurement applications in electricity, transportation, etc. Our Industrial Laser Distance Sensor supports data communication via bluetooth,RS232,RS485,USB,BeagleBoard,Renesas controller,and also can be applied to Arduino, Raspberry Pi, UDOO, MCU etc. It`s different from other sellers ,we can produce low price laser distance module as your demand and provide consistently technique support and after sales service for customers.

Industrial Laser Distance Sensor Feature:

1. Good for Industrial laser distance sensor

2. Support single measurement/continous measurement

3. Data output: RXTX, USB, RS232, RS485, Bluetooth optional

Specifications of Industrial Laser Distance Sensor:

Brand Name JRT
Product Name OEM Industrial Laser Distance Sensor with RS232
Model Number B605B
Certification FDA/ISO9001/CE/ROHS/FCC
Place of Origin China
Accuracy ±1 mm (0.04 inch)
Measuring Unit meter/inch/feet
Measuring Range (without Reflection) 0.03-150m
Measuring Time 0.125~4 seconds
Laser Class Class II
Laser Type 635nm, <1mW
Size

72*40*18mm (±1 mm)
Weight About 25g
Voltage DC2.0~3.3V
Electrical Level TTL/CMOS
Frequency 3HZ~8Hz
Storage Temperature -25~60 ℃ (-13~140 ℉)
Operating Temperature 0-40 ℃ (32-104 ℉ )
Packaging Neutro-packing

1. Under bad measure condition, like environment with strong light or the diffuse reflectance of measuring point over-high or low, the accuracy would have bigger amount of error: ±1 mm+40PPM.

2. Under strong light or bad diffuse reflectance of target, please use a reflector.

3.120m,150m can be customized.

4. Voltage can be changed by power converter LDO

5. Frequency would be affected by environment.

6. Operating temperature -10 ℃~50 ℃ can be customized.
