GDZ65F-800 800w CNC Spindle Motor Mount 65 Mm 18000rpm
GDZ65F-800 800w CNC Spindle Motor Mount 65 Mm 18000rpm
Specifications
Brand Name :
JSS
Model Number :
GDZ65F-800
Certification :
CE,ROHS,ISO
Place of Origin :
Jiangsu, China
MOQ :
1
Price :
negotiate
Payment Terms :
T/T,Paypal,credit card, Western Union
Supply Ability :
2000pcs per weeks
Delivery Time :
20 work days
Packaging Details :
cartons
product name :
air cooler spindle motor
Key words :
spindle motor
ODM :
support
Application :
cnc router
Operating speed :
18000rpm
Voltage :
220V
Frequency :
400HZ
Cooling type :
air Cooling
Weight :
3kg
Diameter :
65mm
Lubrication :
Grease
Bearing type :
2*7002C P4 + 2*7000C P4
current :
5.5A
Description

cnc router air cooler spindle motor round shape 800w 18000rpm spindle

Changzhou Jinsanshi Mechatronics Co. Ltd. is located in Changzhou city, Jiangsu province, China. We are a comprehensive company which specializes in producing and researching motors and drivers. Our main products include hybrid step motor, and step driver, step servo motor and driver, integrated step servo motor, linear stepper motor, geared stepper motor, stepper motor with brake, brushless dc motor. And we are always researching and developing new products.

1. Imported bearings; bearings with dust cover, more secure

2. Using grinding process, can improve motor concentricity and prolong life

3. Air-cooled motor, sculpture forceful, high precision, long life

Product Description

Product Features

speed:18000rpm

power :800w

Dia:65mm

The datasheet of our water cooling spindle motor

TYPE speed (rpm) power(kw) voltage (V) current (A) frequency (HZ) dimension collect product size(mm) Weight(kg)
L4 L5 L6 L1 L2 L3
round GDZ65F-800 24000 0.8 220 4 400 65 ER11 182.5 15 28.5 3
GDZ80F-1.5 24000 1.5 220 5 400 80 ER11 193.5 9 26 4.4
GDZ80F-2.2 24000 2.2 220 8 400 80 ER16 193.5 19.5 31.5 4.5
GDZ80F-2.2 24000 2.2 220 8 400 80 ER20 193.5 19.5 31.5 4.5
