Cnc Router Plotter Square ER25 Spindle Motor 18000rpm 3.5kw Gdz93x82-3.5
Cnc Router Plotter Square ER25 Spindle Motor 18000rpm 3.5kw Gdz93x82-3.5
Cnc Router Plotter Square ER25 Spindle Motor 18000rpm 3.5kw Gdz93x82-3.5
Cnc Router Plotter Square ER25 Spindle Motor 18000rpm 3.5kw Gdz93x82-3.5
Cnc Router Plotter Square ER25 Spindle Motor 18000rpm 3.5kw Gdz93x82-3.5
Cnc Router Plotter Square ER25 Spindle Motor 18000rpm 3.5kw Gdz93x82-3.5
Specifications
Brand Name :
JSS
Model Number :
GDZ93*82-3.5
Certification :
CE,ROHS,ISO
Place of Origin :
Jiangsu, China
MOQ :
1
Price :
negotiate
Payment Terms :
T/T,Paypal,credit card, Western Union
Supply Ability :
2000pcs per weeks
Delivery Time :
20 work days
Packaging Details :
cartons
product name :
spindle motor air cooled
Key words :
spindle motor
ODM :
support
Application :
engraving cnc route
Operating speed :
18000rpm
Voltage :
380V
Frequency :
300HZ
Cooling type :
air Cooling
Weight :
9kg
Diameter :
93*82mm
Lubrication :
Grease
Bearing type :
2*7007C P4 + 2*7002C P4
current :
8.8A
collet :
ER25
Description

engraving cnc route plotter square spindle motor 3.5kw 18000rpm

Our products are exported to all over the world, including Europe, South America, North America, Africa, Southeast Asia, etc.

We can solve the actual using problems for customers. Our products are highly commended by customers because of its easy operation, long using life, stable performance.

our main products:

hybrid stepper motor and drives

Brushless DC motor and drives

planetary gearbox

AC servo motor

Spindle motor

Linear guide and its pairs

Ball screw and its pairs

Product Description

Product Features

speed:18000rpm

power :3.5Kw

Voltage :220V or 380V

size:93*82

collet: ER25

The datasheet of our air cooling spindle motor

TYPE speed (rpm) power(kw) voltage (V) current (A) frequency (HZ) dimension collect product size(mm) Weight(kg)
L4 L5 L6 L1 L2 L3
round GDZ65F-800 24000 0.8 220 4 400 65 ER11 182.5 15 28.5 3
GDZ80F-1.5 24000 1.5 220 5 400 80 ER11 193.5 9 26 4.4
GDZ80F-2.2 24000 2.2 220 8 400 80 ER16 193.5 19.5 31.5 4.5
GDZ80F-2.2 24000 2.2 220 8 400 80 ER20 193.5 19.5 31.5 4.5
square GDZ93*82-1.5 18000 1.5 220 380 6.6 3.8 300 45 30 20 ER20 137 44.5 37 6
square GDZ93*82-2.2 18000 2.2 220 380 8 4.6 300 45 30 37 ER25 173 48.5 37 8
square GDZ93*82-3.5 18000 3.5 220 380 13 7.5 300 45 30 37 ER25 214 48.5 37 9



Motor size :

Cnc Router Plotter Square ER25 Spindle Motor 18000rpm 3.5kw Gdz93x82-3.5

Cnc Router Plotter Square ER25 Spindle Motor 18000rpm 3.5kw Gdz93x82-3.5Suitful pairs:

Cnc Router Plotter Square ER25 Spindle Motor 18000rpm 3.5kw Gdz93x82-3.5

Cnc Router Plotter Square ER25 Spindle Motor 18000rpm 3.5kw Gdz93x82-3.5
