Gdz 80-1.5 CNC 1.5kw Spindle Motor For Cnc Router Air Cooled Round 24000rpm
Gdz 80-1.5 CNC 1.5kw Spindle Motor For Cnc Router Air Cooled Round 24000rpm
Gdz 80-1.5 CNC 1.5kw Spindle Motor For Cnc Router Air Cooled Round 24000rpm
Gdz 80-1.5 CNC 1.5kw Spindle Motor For Cnc Router Air Cooled Round 24000rpm
Specifications
Brand Name :
JSS
Model Number :
GDZ80F-1.5
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
800pcs/day
Delivery Time :
15days
Packaging Details :
Cartoon box
Name :
Air cooled spindle motor
speed (rpm) :
24000
power (kw) :
1.5
voltage (V) :
220
current (A) :
5
Frequency (HZ) :
400
collect :
ER11
Weight (kg) :
4.4
Size :
Φ80
Description

Router CNC air cooled spindle motor round type 1.5kw 24000rpm

Company informations:

Changzhou Jinsanshi Mechatronics Co. Ltd. is a comprehensive company which specializes in producing and researching stepper motor and motor driver. Our company is located in Changzhou city, Jiangsu province, China. We own an excellent group with rich experience in manufacturing and researching. In this field, we have rich experience, so that we can solve the actual using problems for customers. Our products are highly commended by customers because of its easy operation, long using life, stable performance, low failure rate and high technical content.

Application:

Milling Machine, Turning Machine, Engraving Machine, Grinding Machine, MotorcycleMachine

The datasheet of our air cooling spindle motor

TYPE

speed

(rpm)

power

(kw)

voltage

(V)

current

(A)

frequency

(HZ)

 dimension collect product size(mm)

Weight

(kg)
L4 L5 L6 L1 L2 L3
round GDZ65F-800 24000 0.8 220 4 400 Φ65 ER11 182.5 15 28.5 3
GDZ80F-1.5 24000 1.5 220 5 400 Φ80 ER11 193.5 9 26 4.4
GDZ80F-2.2 24000 2.2 220 8 400 Φ80 ER16 193.5 19.5 31.5 4.5
GDZ80F-2.2 24000 2.2 220 8 400 Φ80 ER20 193.5 19.5 31.5 4.5
square GDZ93*82-1.5 18000 1.5 220 6.6 300 45 30 20 ER20 137 44.5 37 6
380 3.8
GDZ93*82-2.2 18000 2.2 220 8 300 45 30 37 ER25 173 48.5 37 8
380 4.6
GDZ93*82-3.5 18000 3.5 220 13 300 45 30 37 ER25 214 48.5 37 9
380 7.5
GDZ93*82-3.5D 18000 3.5 380 7.5 300 45 30 37 ER25,ER25 201.5 48.5 30.5 9.5
GDZ120x103-4.5 18000 4.5 220 17.3 300 60 36 25 ER32 190 56.5 46.5 13
380 10
GDZ120*103-6 18000 6 220 20.8 300 60 36 40 ER32 233 56.5 46.5 15
380 12
GDZ120*103-7.5 18000 7.5 380 14.5 300 60 36 13 ER32 272 56.5 46.5 18
GDZ170*150-12 18000 12 380 22 300 60 50 30 ER32orER40 279 67.5 41 28

Product Description

Produce process

Gdz 80-1.5 CNC 1.5kw Spindle Motor For Cnc Router Air Cooled Round 24000rpm

Our Services

Different specification of stepper motor with competitive price for your choice:

Gdz 80-1.5 CNC 1.5kw Spindle Motor For Cnc Router Air Cooled Round 24000rpm

A wide range of application:

Our stepper motor are widely used in engraving machine, cutting plotter, textile machine, 3D printer, medical devices, stage lighting equipment, robot, CNC machine, music fountain and other industrial automatic equipment.

Gdz 80-1.5 CNC 1.5kw Spindle Motor For Cnc Router Air Cooled Round 24000rpm

First-class service:

customization and OEM is available.

Warranty: 12 months

Contact Us: We 24 hours service for you! If you have any questions about our products, pleasee contact us without any hestation. It's a pleasure to serve you.

Contact me :

WhatsApp: +86 18306110590

Phone: +86 18306110590

Packaging & Shipping

We have standard package for our products. We can also make it as per your special requirements.

Gdz 80-1.5 CNC 1.5kw Spindle Motor For Cnc Router Air Cooled Round 24000rpm

Shipping can be arranged as per your requirements. Air and sea transportation are both acceptabel.

FAQ

1.Q:Can I get some samples first?

A:Sure, we are honored to offer you samples for your check.

2.Q:Do you have the products in stock?

A:Our products are manufactured according to your order except the normal products.

3.Q:What's the delivery time?

A:It usually takes about 7 working days,but the exact delivery time might be different for different order or at different time.

4.Q: How does your factory do regarding quality control?

A: Quality is priority. We always attach great importance to quality control from the beginning to the end of the production. Every product will be fully assembled and carefully tested before packed.

5.Q:What's your warranty terms?
A: We offer different warranty terms for different products. Please contact with us for details.
