Build-in access controller and Digital keyboard Manage
Operating Mode: Proximity Card

Specification
Supply Voltage: DC12V
Working Current: less than 1000 mA
Static current: less than 80 mA
User capacity: 200/800 Card and 200 passwords
Proximity distance: more than 5CM
Support Card type: EM-ID (125 KHz) or Mifare Card
Operation Temperature: -10 C-70 C
Operation Humidity: 10%-90%

Programming.
*Press Key # four times, the Buzzer make long sound BI, POWER (Red), OK (Green), Mode (Yellow) is on at the same time.
*Input 5 digits PIN (Default Password is 12345), OK (Green) is off. The machine enters Making Program Status.
*Press key 2, MODE light (Yellow) is on, POWER (Red) and OK (Green) light are off.
*Input 4 character password to open a door (Such as: 0008), the POWER (Red) and OK light (Green) flash.
*Read the user card that needs log in, a sound BI will be heard, POWER light (Red) is off, OK (Green) and MODE light (Orange) are on, the user card is registered successfully.
*Input 4 digits PIN for opening the door, OK (Green) is off, POWER (Red) is on, which showing PIN is registered.
*Press Key 6 to Exit programming status.

Other Setting:
Change Program Operating Password
*Press key 1, The MODE (Yellow) light is on, POWER (Red), OK (Green) light is off.
*Input PIN as your will (Example, 23456), the Buzzer make a short sound of BI, OK (Green) is on, POWER (Red), MODE (yellow) is on, PIN has changed successfully. Note: The PIN should be kept; you will need it to enter the Making Program Mode next time. If PIN forgotten, please execute Machine Initial Step.

Delete the single user card
*Press key 3, MODE light (yellow) is bright, POWER (Red) and OK (green) light are off.
*Input 4 character user series No that needs to be deleted. (Series No on card, such as: 0008), a sound BI will be heard. This means the deletion is successful.

Delete all registered cards
*Press key 4, BI will be heard twice. All the registered cards and passwords are deleted.

Open Door Time Setting
*Press key 5, MODE light (Yellow) is bright, POWER (Red) and OK (Green) are off.
*Input 2 character as the door open time (Such as: 05, means that the door open time is 5 second), sound BI will be heard twice, this means the door open time setup is successful.

Note: The default open time is 3 second
