FR4 Multilayer SMT Assembly Service Thick Copper PCBA Motherboard Circuit Board
FR4 Multilayer SMT Assembly Service Thick Copper PCBA Motherboard Circuit Board
Specifications
Brand Name :
JIETENG
Model Number :
PCBA
Certification :
ISO/TS16949/RoHS/TS16949
Place of Origin :
Guangdong, China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
Negotiable
Supply Ability :
200000 Piece/Pieces per Month
Delivery Time :
3-8 days delivery
Packaging Details :
1. at buyer's request; 2. inner, vaccum package; 3. outer, standard export carton
Applicable components :
0805
Application :
Electronics Device
Usage :
LED SMT Large Qty Production
Weight :
approx.270KGS
Description

PCBA program development design FR4 multilayer circuit board thick copper plate production processing

Essential details
Model Number:
PCB
Type:
Multilayer pcb
Place of Origin:
Guangdong, China
Brand Name:
JIETENG
Number of Layers:
2 layers 4 layers
Base Material:
FR-4, FR-4
Copper Thickness:
1/2 oz min; 12 oz max
Board Thickness:
0.2mm-6mm(8mil-126mil)
Min. Hole Size:
0.1mm(4mil)
Min. Line Width:
0.075mm(3mil)
Min. Line Spacing:
0.1mm(4mil)
Surface Finishing:
HASL / HASL lead free, OSP, ENIG, Gold Plating
Board Size:
all
Product name:
OEM pcb controller board for guitar/bass pedals blank PCB board
Service:
One-stop Service
Solder mask color:
Black.Red.Yellow.White.Blue.Green
Material:
FR4 /aluminum/FR-4 CTI300

PCB Manufacture Capacity
Item Specification
Material FR-4, FR1,FR2; CEM-1, CEM-3,Rogers, Teflon,Arlon,Aluminum Base, Copper Base,Ceramic, Crockery, etc.
Remarks High Tg CCL is Available(Tg>=170℃)
Finish Board Thickness 0.2 mm-6.00mm(8mil-126mil)
Surface Finish Gold finger(>=0.13um), Immersion Gold(0.025-0075um), Plating Gold(0.025-3.0um), HASL(5-20um), OSP(0.2-0.5um)
Shape Routing,Punch,V-cut,Chamfer
Surface Treatment Solder Mask(black, green, white, red, blue, thickness>=12um, Block, BGA)
Silkscreen(black, yellow, white)
Peel able-mask(red, blue, thickness>=300um)
Minimum Core 0.075mm(3mil)
Copper Thickness 1/2 oz min; 12oz max
Min Trace Width & Line Spacing 0.075mm/0.075mm(3mil/3mil)
Min Hole Diameter for CNC Drilling 0.1mm(4mil)
Min Hole Diameter for Punching 0.6mm(35mil)
Biggest panel size 610mm * 508mm
Hole Position +/-0.075mm(3mil) CNC Drilling
Conductor Width(W) +/-0.05mm(2mil) or +/-20% of original
Hole Diameter(H) PTHL:+/-0.075mm(3mil)
Non PTHL:+/-0.05mm(2mil)
Outline Tolerance +/-0.1mm(4mil) CNC Routing
Warp & Twist 0.70%
Insulation Resistance 10Kohm-20Mohm
Conductivity <50ohm
Test Voltage 10-300V
Panel Size 110 x 100mm(min)
660 x 600mm(max)
Layer-layer misregistration 4 layers:0.15mm(6mil)max
6 layers:0.25mm(10mil)max
Min spacing between hole edge to circuitry pattern of an inner layer 0.25mm(10mil)
Min spacing between board outline to circuitry pattern of an inner layer 0.25mm(10mil)
Board thickness tolerance

4 layers:+/-0.13mm(5mil)

FR4 Multilayer SMT Assembly Service Thick Copper PCBA Motherboard Circuit Board
