Product Description:

The surface finish of our multi-layer PCB manufacturing products is ENIG, which stands for Electroless Nickel Immersion Gold. This surface finish provides excellent conductivity and a flat surface for easy soldering.
We understand the importance of precision in PCB production, which is why we offer a minimum aperture of 0.2mm. This improves the accuracy and reliability of your electronic devices. Our materials are halogen-free, KB, ensuring your PCBs are environmentally friendly and safe to use.
Our multi-layer PCB manufacturing products have a board thickness of 1.5mm, providing a strong and durable foundation for your electronic components. You can trust that your PCBs will be manufactured with precision and care.

Features:

• Product Name: Multilayer PCB Fabrication
• Impedance Control: Yes
• Layer Count: 10-Layer
• Material: Halogen Free, KB
• Min. Hole Size: 0.2mm
• Silkscreen Color: White

This product is a Multi-Layer PCB Manufacturing that offers Impedance Control, with a Layer Count of 10-Layer, made of Halogen Free, KB Material, with a Min. Hole Size of 0.2mm, and Silkscreen Color in White.

Applications:

One of the most notable advantages of Jieteng Circuit Co., Ltd.'s multi-layer PCB manufacturing is its ability to manufacture multi-layer printed wiring boards. This feature makes it an ideal solution for applications that require complex circuit design and high-density interconnection, such as telecommunications, communications, and high-speed computing systems.

With a copper thickness of 1OZ and material options including halogen-free and KB, this product is designed to meet the most demanding requirements of modern electronic devices. The minimum aperture of 0.2mm allows for precise placement of components and tight wiring, ideal for applications that require high precision and accuracy.

The board thickness of 1.5mm and the surface treatment of ENIG further enhance its capabilities, making it an ideal solution for applications that require high signal integrity and reliability.

Some common applications and scenarios for Jieteng Circuit Co., Ltd.'s multi-layer PCB manufacturing include telecommunications, communications, computer systems, medical devices, aerospace, and defense industries. The high-quality structure and performance of this product make it an ideal solution for applications that require complex circuit design, high-density interconnection, and reliable performance.
