Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Specifications
Brand Name :
OEM
Model Number :
JTN-M340W-B, JTN-M220W-B
Place of Origin :
Guangdong, China
Packaging Details :
packing in carton box
Supply Ability :
5000000 Piece/Pieces per Month
MOQ :
100000 watts
Price :
$0.30/watts 100000-199999 watts
Cell size :
156.75mmx156.75mm, 125mm*125mm/Other
Type :
PERC, Half Cell, All Black, BIPV
Panel Dimensions :
customization
Panel Efficiency :
19.8%-22.5%
Warranty :
3years
Protable Name :
Home Use Solar Panel
Waterproof :
IP65
Logo print :
customization
Workmanship :
12 years
Solar cell :
Monocrystalline
Surface material :
PET/ETFE/Glass
Output mode :
MC4/DC/Anderson
Connector :
Compatible Connector or customized
Port :
SHENZHEN
Description
Hot Sale 340Wp Pv Mould 72 Cell 340W Mono Half Cell Solar Panel
Products Description
Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Model
JTN-(XXX)W-B (XXX)=Pmax/W
JTN-(XXX)W-B (XXX)=Pmax/W
Maximum Power(Pmax/W)
100
150
160
200
250
300
Open-circuit Voltage (Voc/V)
21.6
32.14
21.6
43.4
33.33
39.3
Short-circuit Current (Isc/A)
6.1
6.1
9.7
6.1
9.9
10.08
Maximum Power Voltage(Vmp/V)
18
26.8
18
36.2
27.8
32.75
Maximum Power Current (Imp/A)
5.6
5.6
8.9
5.5
9
9.16
Solar Panel Efficiency(%)
19.8-22.5%
19.8-22.5%
Power Tolerance(W)
0~+5W
0~+5W
Standard Test Environment
Irradiance 1000w/m2, Ambient temperature 25℃, Spectrum AM 1.5
Model
JTN-M(XXX)W-B (XXX)=Pmax/W
Maximum Power(Pmax/W)
370
400
450
455
480
customize
65.29Open-circuit Voltage (Voc/V)
28.8
21.6
24
26.4
33.6
/
Short-circuit Current (Isc/A)
17
24.4
24.75
22.75
18.9
/
Maximum Power Voltage(Vmp/V)
24
18
20
22
28
/
Maximum Power Current (Imp/A)
15.4
22.2
22.5
20.7
17.1
/
Solar Panel Efficiency(%)
19.8-22.5%
Power Tolerance(W)
0~+5W
Standard Test Environment
Irradiance 1000w/m2, Ambient temperature 25℃, Spectrum AM 1.5
Model
JTN-M(XXX)W-B (XXX)=Pmax/W
Maximum Power(Pmax/W)
500
535
540
545
550
customize
Open-circuit Voltage (Voc/V)
43.2
28.8
26.4
88.02
88
/
Short-circuit Current (Isc/A)
15.28
24.5
27
8.17
8.25
/
Maximum Power Voltage(Vmp/V)
36
24
22
7.43
7.5
/
Maximum Power Current (Imp/A)
13.9
22.3
24.6
7.43
7.5
/
Solar Panel Efficiency(%)
19.8-22.5%
Power Tolerance(W)
0~+5W
Standard Test Environment
Irradiance 1000w/m2, Ambient temperature 25℃, Spectrum AM 1.5
Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Integrated Half Cell Poly Mono Solar Panel 340Wp For Home
Q :Are you manufacturer or trading company?
A : We are manufacturer with more than 10 years experience and can control the production of goods quality and delivery time.

Q : What kind of certificates your products have?
A : CE,FCC,RoHS,PSE,MSDS

Q : What's your products MOQ?
A : MOQ is 50 pcs.

Q : How about your delivery time?
A : Generally,our stock products would be shipped in 1-3 days after payment received. finally depends on order quantities.

Q : What's your warranty?
A : All our products will be 100% test before shipment. Warranty 2 years.

Q : What is the payment method?
A: We accept payment by T/T, Credit card, Alibaba platform, Western Union and etc.
