JYF100 High Efficiency 75kw 100 Hp Air Compressor Variable Frequency
JYF100 High Efficiency 75kw 100 Hp Air Compressor Variable Frequency
Specifications
Brand Name :
JUCAI
Model Number :
JYF100
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T Pay 30% deposit first, L/C, Western Union
Packaging Details :
Environmental protection wooden box packaging
Model :
JYF100
Volt/Ph/Hz :
380/3/50
Power KW/HP :
37/50
Pressure bar :
8
Dimension :
1740*1260*1620
Weight :
1100kg
Description

JYF100 High Efficiency 75kw 100 Hp Air Compressor Variable Frequency

Screw Air Compressor 75kw General Industrial Equipment

JYF100 75kw 100hp Variable Frequency Screw Air Compressor Highly Quality General Industry High Efficiency Air Compressor

Remote IoT monitoring system

Remote IoT detection system, equipment full life cycle management, online monitoring remote management, mobile phone warning, data collection

Specifications

Model JYF10 JYF15 JYF20 JYF30 JYF50 JYF75 JYF100
Volt / Ph / Hz 380/3/50 380/3/50 380/3/50 380/3/50 380/3/50 380/3/50 380/3/50
Power KW / HP 7.5/10 11/15 15/20 22/30 37/50 55/75 75/100
Pressure bar 8 8 8 8 36.2 8 8
Flow m³/min 1.1 1.75 2.25 3.6 24 9.6 12.5
Lubricant 6 10 10 16 35 53
Noise db(A) 68±2 70±2 70±2 72±2 75±2 77±2 78±2
Air Outlet Pipe Diameter G1/2 G3/4 G3/4 G3/4 G1 1/2 G1 1/2 DN40
Dimension 900*700
*910		 1080*780
*1020		 1080*780
*1020		 1080*880
*1220		 1200*1000
*1400		 1560*1140
*1440		 1740*1300
*1610
Weight (KG) 170 260 270 350 500 940 1220

Main Features
1) 7bar/8bar/10bar/12.5bar working pressure(discharge pressure) for your selection (for more lower pressure 4bar or 6bar, or more high pressure to 30bar, 300bar, 400bar, etc, please send your inquiry to us.
2) Intelligent microcomputer control system, controller has the remind & record function, Unattended, remote monitoring
3) Superior components, low maintenance cost
4) Failture Alarm to very easy to do the maintenance, and remind the regular replacement.
5) Oversize air-end, low rpm, no overheat problem
6) IP54/IP55 high quality motor Class F level insulation; Class B Temperature rise;
7) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
8) Running in a high automatization and intellectualization,no pollution
9) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .

Product introduction

JYF100 High Efficiency 75kw 100 Hp Air Compressor Variable Frequency

Intelligent comtrol

The intelligent controller of Chinese&English interface supervises the operation of the compressor in real time. Its auto warning protection function solves the problems of short-circuit,missing phase,overload or else.If the abnormal condition exits after checking the multi-point temperature and pressure,it will alarm and shut downautomatically. The equipment up-time and state is recorded to remind the equipment to make a repair

and maintain. According to the gas consumption,it can control the discharge rate to distinct energy-saving effectg.

JYF100 High Efficiency 75kw 100 Hp Air Compressor Variable Frequency

Cooler

A huge design of cooler volume to discharge 35% margin.As a result, a machine can operate at high temperature and avoid the phenomenon of carbon deposit caused by the high temperature of the compressor.

JYF100 High Efficiency 75kw 100 Hp Air Compressor Variable Frequency

Electrical components

Electrical components are made by the world famous brands,Schneider and Siemens which use silver contact to make it possible to operate more thanthree million times and ensure the longtermuse safety.

JYF100 High Efficiency 75kw 100 Hp Air Compressor Variable Frequency

Screw host

The screw host is from a famous brand of European which determined the excellent performance of the machine as a"strong heart".

JYF100 High Efficiency 75kw 100 Hp Air Compressor Variable Frequency

Inlet valve

None is easily damaged with an ON-OFF regulation and the adjusting range of tidal volume is 0 to 100%. It has small pressure loss and long operating life.At present,it is the most effective and reliable adjusting method of intake.

JYF100 High Efficiency 75kw 100 Hp Air Compressor Variable Frequency

Main motor

It adopts triphase high performance motor made by a famous brand with IP54 PROTECTION LEVEL,

F insulation level and"SKF"heavy-duty bearing.The transmission efficiency up to 95%,

whit good thermostability and longlifetime.

Wide range of application

JYF100 High Efficiency 75kw 100 Hp Air Compressor Variable Frequency

FAQ:

1 What trade terms do we provide? What kind of settlement currency do we offer?
Trade term :CIF ,CFR ,FOB,Ex-Works As far Our business traded in Dollars ,Euros and RMB .


2 How long is our delivery?
Our standard delivery time is 30-40 days after confirmation order & receiving recipets for standard compressors, for the other non standard requirement will be discussed case by case.

3 What is the voltage of the compressor?
The available voltage include 380V/50HZ/3Phase, 400V/50HZ/3P, 415V/50HZ/3P, 220V/60HZ/3P, 380V/60HZ/3P, 440V/60HZ/3P. At the same time we provide other voltage according to customer requirement.

4 Can our compressor run in high temperature environment? What is the working temperature range for our machine?
Yes ,our machine would run in high temperature environment ,until now our products have been sold to many countries which wouldmeet high temperature in summer ,such like Iraq, Saudi Arabia, Egypt, Algeria, etc. Work temperature range :1-45 ℃(33.8℉-113℉)

5 What’s the min. Order requirement ?
Min. Order requirement is 1PCS.
