Specifications
Place of Origin :
Shandong, China
Brand Name :
Junxu Group
Condition :
New
Machine Type :
3-5 8-10 cubic meters
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
Hot Product
Warranty of core components :
1 Year
Core Components :
Engine
Warranty :
1 Year
Weight (KG) :
2000 KG
Power (kW) :
15KW
Key Selling Points :
Fully automatic control
Showroom Location :
Africa Vietnam
Applicable Industries :
Wood processing plant, Wooden Factory, Wood Industry Company, Furniture Company, Board factory
Name :
High frequency vacuum drying machine for wood
Usage :
Drying Wood
Voltage :
customization
Motor power :
customization
Color :
Customers Requirement
Overall dimensions (mm) :
customization
Total Power :
customization
Size :
customization
Scope of application :
Materials
Brand :
Junxu
Price :
$6,500.00/sets 1-1 sets
MOQ :
1
Description
Specification
Machine Type
Wood High-Frequency Vacuum Drying Machine
Marketing Type
Popular products
Weight (KG)
Over 2000 kilograms
Power (kW)
15KW
Key Selling Points
Fully automatic control for short drying time, no cracking or deformation
Showroom Location
Africa Vietnam
Applicable Industries
Wood processing factories, woodworking factories, timber companies, furniture companies, and board factories
Product Description
8 Cubic Meters HF Vacuum Steam Technology Wood Drying Kiln for Precise Drying Results
8 Cubic Meters HF Vacuum Steam Technology Wood Drying Kiln for Precise Drying Results
8 Cubic Meters HF Vacuum Steam Technology Wood Drying Kiln for Precise Drying Results
8 Cubic Meters HF Vacuum Steam Technology Wood Drying Kiln for Precise Drying Results

Working principle of high-frequency vacuum dryer:

High frequency vacuum drying is a combined drying method of high-frequency medium heating and vacuum low-temperature drying, which is a fast and almost waste free drying method, especially suitable for drying hardwood and heavy wood. High frequency heating: Also known as high-frequency medium heating, it converts a regular 380V AC power supply into a high-frequency electromagnetic field after boosting and rectifying it. High frequency heating can be achieved through related supporting equipment with anode and cathode plates.
High frequency heating is penetration heating, where the moisture in the electric field is uniformly heated. The parts with more moisture absorb more high-frequency electric fields, while the parts with less moisture only absorb a small amount of high-frequency electric fields. This effectively utilizes the high-frequency output power. However, media such as wood or fiber, due to their lack of polarity, do not absorb electric fields, and high-frequency power is basically used without waste, saving energy consumption and reducing drying costs.
Vacuum state mainly utilizes the lower boiling point of water in vacuum state, which accelerates the evaporation rate and increases the gradient of moisture content on the surface of wood. During the drying process, on the one hand, surface moisture evaporates into the surrounding air, and on the other hand, internal moisture continuously moves towards the surface, thus accelerating the drying rate at lower temperatures, ensuring the drying quality of wood. The vacuum state is a negative pressure state that has a certain water absorption effect, which is exactly similar to the high-frequency pressure gradient and accelerates the discharge of moisture from the wood core. In addition, under low pressure conditions, the oxygen in the drying medium causes less discoloration of the material due to thermal and oxidation effects, which can basically maintain the natural color of precious wood.
Based on the above characteristics, the application of high-frequency vacuum drying in wood drying has become a scientific and environmentally friendly drying method, especially suitable for drying hardwood with a large cross-section.

Characteristic

1、 The use of high-frequency heating solves the problem of rapid heating and drying of wood. 2、 The wood is heated both inside and outside, evenly and of good quality, which can maintain the natural color of the wood. 3、 The use of vacuum water absorption reduces the temperature of the wood drying process, causing the wood to vaporize at low temperatures, making it less prone to cracking and improving the dehydration rate of the wood. 4、 Environmentally friendly and non polluting. 5、 High frequency waves can kill insects and bacteria hidden inside the board, while shortening the drying cycle and further ensuring the quality of wood drying. Especially suitable for drying thick, hard, large section square wood (conventional drying methods require a long time), precious rosewood wood such as rosewood, chicken wing wood, yellow pear, etc., as well as drying wooden floors. At the same time, secondary drying of small batches and expedited wood after moisture regain is also used.

Configuration

1. Intelligent human-machine interface automatic control, control personnel only need to set basic parameters such as drying process, initial moisture content, and required final moisture content, and the drying process is all automatically controlled by the program. 2. High frequency automatic tuning, without the need for personnel adjustment, the fault detection system can detect the working status of the equipment at any time. If there is a fault, the equipment will be powered off and an alarm will be given and fault information will be prompted. 3. The humidity detection adopts online real-time monitoring of moisture content,? The moisture content of wood can be detected at any time to ensure the accuracy of moisture content monitoring. 4. The temperature adopts a fiber optic temperature detection device, which is accurate and not affected by high-frequency interference. Temperature detection is only used to ensure the drying effect, avoiding the problem of serious data errors in the detection of ordinary metal probes in the electric field.
Model
JXZG--3
JXZG---6
JXZG---8
Effective size of wood stacking
1000*1000*3000mm
1000*1000*6000mm
1000*1000*8000mm
Effective volume
3 cubic meters
6 cubic meters
8 cubic meters
High frequency power
30kW
40kW/50kW
50kW
High frequency
6.78MHz
Hydraulic system
2T
4T
4T
Vacuum system 5.5kW 7.5kW 7.5kW drying steam cooling 5-ton cooling tower 10 ton displacement cooling tower 10 ton cooling tower
