1.4404 S30403 316 Stainless Steel Coil , 1000 - 1550mm Width Steel Sheet Coil
1.4404 S30403 316 Stainless Steel Coil , 1000 - 1550mm Width Steel Sheet Coil
Specifications
Brand Name :
Baosteel Hongwang Jisco Yongjin
Model Number :
SUS316L 1.4404 S31603
Certification :
ISO9001 14001
Place of Origin :
made in CHINA
MOQ :
negotiation
Price :
negotiation
Payment Terms :
by T/T in advance OR by irrevocable L/C at sight
Supply Ability :
5000T/M
Delivery Time :
around 30dd
Packaging Details :
Standard Export Packing
Grade :
SUS316L 1.4404 S31603
Thickness :
0.3-3.0mm
Width :
1000-1550mm
Edge :
MIll edge or Slit edge
Tolerance for mill edge :
+/-15mm
Country of Origin :
Made in China
Lead time :
30dd
Description

1000mm~1550mm 316L cold rolled stainless steel coils SUS316L 1.4404 S30403

316L cold rolled stainless steel coils

  • Description of goods: 316L Cold rolled stainless steel coils
  • Serie: 300series
  • Grade: SUS316L 1.4404 S31603
  • Thickness:0.3-3.0mm
  • Finish 2B 2D BA NO.4 HL FH PVC/PE
  • Width:1000-1550mm
  • Standard: JIS ASTM AISI ASME EN
  • Coil ID: 508 or 610mm
  • Thickness tolerance:to be defined with customers
  • Surface treatment:Cold rolled,annealed, pickled
  • Coil weight; 8-10MT,9-11MT 4-6MT or as per your request
  • Paper Interleaved: Yes
  • Q'ty tolerance+/-10% on order quantity
  • Edge: MILL/SLIT

Main Commercial Conditions:

Payment terms by T/T in advance or by irrevocable L/C at sight
Packaging Seaworthy standard export package with pallet
Shipping date about a month
Shipping terms FOB CFR CIF etc.
Country of Origin Made in China

CHEMICAL COMPOSITION of 316L

In accordance with different Normatives, there are different prescription on each chemical elements:

see here below the specific table:

STANDARD GRADE CHEMICAL COMPOSITION %
C max Si max Mn max P max S max N max Ni Cr Mo
JIS SUS316L 0.03 1.00 2.00 0.045 0.03 - 12.00~15.00 16.00~18.00 2.00~3.00
ASTM S31603* 0.03 0.75 2.00 0.045 0.03 0.10 10.00~14.00 16.00~18.00 2.00~3.00
EN 1.4404 0.03 1.00 2.00 0.045 0.015 0.11 10.00~13.00 16.50~18.50 2.00~2.50
1.4432 0.03 1.00 2.00 0.045 0.015 0.11 10.50~13.00 16.50~18.50 2.50~3.00
1.4435 0.03 1.00 2.00 0.045 0.015 0.11 12.50~15.00 17.00~19.00 2.50~3.00

MECHANICAL PROPERTIES OF 316L

Tensile Strength (N/mm2) :480 MIN

Yield Strength (N/mm2):175 MIN

Elongation (%) :40 MIN

Density: 7.98g/cm3,

Hardness: HRB<90 HV<200 HBS<187

MAIN APPLICATIONS FOR GRADE 316L:

  • Instruments used in seawater, chemical dyes, paper, oxalic acid, fertilizer and other production equipment;
  • Heat exchanger for paper making equipment , dyeing machinery, film washing equipment, pipeline, Construction and building materials used in coastal areas.
  • Luxury watch chain and shell
  • Photography, food industry, coastal facilities, rope, CD rod, bolt, nut etc
