DGD-280BJ PLC Controlled Automatic Horizontal Pouch Packing Machine 380V 50Hz 6kw
DGD-280BJ PLC Controlled Automatic Horizontal Pouch Packing Machine 380V 50Hz 6kw
DGD-280BJ PLC Controlled Automatic Horizontal Pouch Packing Machine 380V 50Hz 6kw
DGD-280BJ PLC Controlled Automatic Horizontal Pouch Packing Machine 380V 50Hz 6kw
DGD-280BJ PLC Controlled Automatic Horizontal Pouch Packing Machine 380V 50Hz 6kw
DGD-280BJ PLC Controlled Automatic Horizontal Pouch Packing Machine 380V 50Hz 6kw
DGD-280BJ PLC Controlled Automatic Horizontal Pouch Packing Machine 380V 50Hz 6kw
DGD-280BJ PLC Controlled Automatic Horizontal Pouch Packing Machine 380V 50Hz 6kw
DGD-280BJ PLC Controlled Automatic Horizontal Pouch Packing Machine 380V 50Hz 6kw
DGD-280BJ PLC Controlled Automatic Horizontal Pouch Packing Machine 380V 50Hz 6kw
DGD-280BJ PLC Controlled Automatic Horizontal Pouch Packing Machine 380V 50Hz 6kw
DGD-280BJ PLC Controlled Automatic Horizontal Pouch Packing Machine 380V 50Hz 6kw
Specifications
Brand Name :
JWIM
Model Number :
DGD-280BJ
Certification :
CE，ISO
Place of Origin :
China
MOQ :
1 set
Price :
negotiation
Payment Terms :
L/C, T/T
Supply Ability :
1 set per month
Delivery Time :
15-90 work days
Packaging Details :
wooden cases
Machine name :
DGD-280BJ Automatic Horizontal Pouch Packing Machine 380V, 50Hz，6kw
Machine frame :
SUS304
Applicable pouch :
Single pouch/Double pouches
Packing volume :
20(Weighing)-40 Pouches/Min
Accuracy :
±1%
Power Source :
Three Phase, AC380V, 50Hz
Power :
6KW
Air Consumption :
840L/MIN
Dimension :
3750×2380×1580mm（L×W×H)
Weight :
3100KG
Control :
PLC
power unit :
Servo motor
Description

DGD-280BJ Automatic Horizontal Pouch Packing Machine

DGD-280AJ Automatic Horizontal Pouch Packing Machine is our newly developed online weighing bagging machine. Under the programmable control of the PLC, the function of bag removal → bag opening → detection → filling → sealing → finished product is realized .

The machine has a patented appearance . It adopts SUS304 arc-shaped frame and tempered glass door cover, with a complete dust removal system, which is suitable for packaging production of various prefabricated bag products.

Parameters of 200g pouch packaging line

1 Capacity

20(Weighing)-40Pouches/Min

*Actual capacity: According to product size, packaging material, material characteristics, etc.
2 Applicable Pouches Size W120-280mm L180-380mm
3 Volume ≤1000g *According to the physical properties of the raw materials and the different feeding devices.
4 Precision

±1g(100g)；≤±2g(200-300g)；≤±3g(300-500g)

≤±3g(500- 1000g)(Optional weighing mode)

*According to the physical properties of the raw materials and the different feeding devices
5 Air pressure 0.6-0.8MPa 500L/MIN
6 Power supply ～380V 50Hz/6.0KW
7 External Dimension 3750×2380×1580mm(L×W×H) *Without powder filling device
8 Weight About 3100Kg
Auxiliary machine of 200g pouch packaging line

SFJ-2 Powder Elevator

Technical Parameters:

1 Power Three Phase AC380V 50HZ/1.5KW
2 Pipe diameter Φ102mm
3 Transportation volume 500-1200kg/hour (actual capacity depends on the characteristic and density of the material)
4 Hopper volume 0.12m³
5 Weight About 100kg
