KZ-1200D Spider Gripper Carton Packing Machine With Small Occupied Space For Improved Efficiency
KZ-1200D Spider Gripper Carton Packing Machine With Small Occupied Space For Improved Efficiency
KZ-1200D Spider Gripper Carton Packing Machine With Small Occupied Space For Improved Efficiency
KZ-1200D Spider Gripper Carton Packing Machine With Small Occupied Space For Improved Efficiency
KZ-1200D Spider Gripper Carton Packing Machine With Small Occupied Space For Improved Efficiency
KZ-1200D Spider Gripper Carton Packing Machine With Small Occupied Space For Improved Efficiency
KZ-1200D Spider Gripper Carton Packing Machine With Small Occupied Space For Improved Efficiency
KZ-1200D Spider Gripper Carton Packing Machine With Small Occupied Space For Improved Efficiency
KZ-1200D Spider Gripper Carton Packing Machine With Small Occupied Space For Improved Efficiency
KZ-1200D Spider Gripper Carton Packing Machine With Small Occupied Space For Improved Efficiency
KZ-1200D Spider Gripper Carton Packing Machine With Small Occupied Space For Improved Efficiency
KZ-1200D Spider Gripper Carton Packing Machine With Small Occupied Space For Improved Efficiency
Specifications
Brand Name :
JINWANG
Model Number :
KZ-1200D
Certification :
CE, ISO9001
Place of Origin :
CHINA
MOQ :
1 set
Price :
negotiation
Payment Terms :
L/C, T/T
Supply Ability :
1 Osets per month
Delivery Time :
15-90 work days
Packaging Details :
wooden cases
Name :
KZ-1200D Spider Gripper Carton Packing Machine
Product Specification :
L10mm~280mm×H10mm~400mm×W10mm~100mm
Applicable Range :
Medicine, Household products, Food Industry
Packing Speed :
≤70 times/minute
Frame Material :
SUS304
Power :
5KW
Overload :
≤3kg (with gripper)
External Dimension :
L2350XW1730XH2360mm
Coordinating Robot :
WSC-1200D
Weight :
1000Kg
Description
KZ-1200D Spider Gripper Carton Packing Machine
1. Introduction
Spider Gripper Carton Packing Machine is self-designed high-speed flexible parallel robot, it ensures that the product does not fall in the process of high-speed grab and handling, It is widely used in automatic identification, sorting, handling and carton packing of bagged products. The machine structure is nicely designed, compact, spare parts less, easy maintenance and repair and low maintenance cost. Occupies a small space, can place in a small space to work to improve the space efficiency. The control mode is hand-held device + standard control button + signal switch, simple operation and convenient management.
KZ-1200D Spider Gripper Carton Packing Machine With Small Occupied Space For Improved Efficiency

2.Equipment Dimension

KZ-1200D Spider Gripper Carton Packing Machine With Small Occupied Space For Improved Efficiency

3.Technical Parameters

1 Applicable Product Specifications L10mm-280mm H10mm-400mm W10mm-100mm
2 Applicable Carton Size L100mm-480mm W100mm-440mm H100mm-300mm
3 Applicable Industry Pharmaceuticals, daily chemicals, food and other industries
4 Packing Speed 30-35 beats/min *Actual capacity varies depending on product size, package material, etc.
5 Passing Rate 99.9%
6 Material Main body frame 304 stainless steel (robot body carbon steel white lacquer)
7 Power Source 380V 50HZ/5KW
8 Rated Load ≤3kg (with grips)
9 External Dimension L2400×W1500×H2200mm(L×W×H)
10 Matching Robot WSC-1200D
11 Weight 1000kg
4.Electrical Configuration
S/N Name Brands
1 Pneumatic Components SMC(Japan)/Air TAC
2 Driving Method HUI CHUAN (Servo Motor)
3 Teaching Pendant KEBA (Austria)
4 Speed Reducer Nippon SHINBO
6 Control System KEBA (Austria)
5. Applicable Specification
KZ-1200D Spider Gripper Carton Packing Machine With Small Occupied Space For Improved Efficiency
6. Applicable Specification
KZ-1200D Spider Gripper Carton Packing Machine With Small Occupied Space For Improved Efficiency
