Product Features:

●Microcomputer control, large LCD screen display, graphical display of current working status, Chinese comment

● Digitize the welding parameters, the keyboard operation is clear and clear, convenient and fast

● Welding voltage locking technology to prevent grid pressure fluctuations from affecting welding current

●The welding pulse width is adjustable, the welding spatter is small, and the solder joints are not discolored.

●Can realize single pulse and double pulse and multi pulse welding

● can store 10 welding specifications

●With two-stage current monitoring and comparison function, the current abnormal sound and light alarm, effectively prevent the occurrence of false welding phenomenon

●With 5-digit counter, calculate the number of successful welding, and also set the counting alarm, prompting to repair the welding pin

● With fault self-diagnosis function, display corresponding fault points, convenient for maintenance

Technical parameters

1. Power supply: AC 220V±10% 50Hz±2Hz Storage capacitor: 9000uf

2. Transformer output maximum power: 25 KVA

3. Output maximum short circuit current: 5000A

4. Pre-welding voltage: 80.0V-330V adjustable, accuracy 0.5V

5. Welding voltage: 80.0V-330V adjustable, accuracy 0.5V

6. Welding time: 1.0ms - 20.0ms adjustable, accuracy 0.1ms

7. Machine weight: 50KG

8. Dimensions: 350L x 180W x 280H (Unit: mm)

9. Scope of application: Maximum thickness of parallel welding: 0.03mm~0.3mm A variety of welding pieces.

Maximum thickness of upper and lower butt welding: 0.3 mm +0.3 mm Multiple welding pieces 10: Can be changed according to customer requirements

Box appearance and control method 11. Suitable for welding of power battery connecting piece and double-layer welding of battery bottom (double

Layer of nickel tabs, copper pole

Ear) such as electric car battery, power battery pack, etc.
