Specifications
Brand Name :
BOE
Model Number :
DV220X2M-NV0
Certification :
ISO9001
Place of Origin :
China
MOQ :
1PCS
Payment Terms :
T/T
Delivery Time :
3-7work days
Packaging Details :
Natural packaging
Size :
22 inch
Resolution :
1920*1920
Interface :
LVDS
Display Mode :
Normally black, Transmissive
Viewing DirLVDS (1 ch, 8bit) , 45 pinsection :
89/89/89/89
Lumiance :
500cd/m² (Typ.)
Active Area(mm) :
398.56*398.56(HxV)
Outline Dimension :
409.56*409.56*12.6mm(HxV)
Operation Temp :
0℃ ~50℃
Storage Temp :
-20℃ ~ +60℃
Description

1920*1920 Tft LCD Display BOE 22 Inch For Industry

BOE 22 inch 1920*1920 LCD display for industrial application

DV220X2M-NV0 is a color active matrix TFT LCD module using amorphous silicon TFT's (Thin Film Transistors) as an active switching devices. This module has a 22 inch diagonally measured active area with 2K resolutions (1920 horizontal by 1920 vertical pixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical stripe and this module can display 16.7M colors. The TFT-LCD panel used for this module is adapted for a low reflection and higher color type.

Features
 LVDS Interface with 4 pixel / clock (Jeida Format)
 High-speed response
 0.5t Glass
 8-bit color depth, display 16. 7M colors
 Incorporated edge type back-light (One Light Bar)
 High luminance and contrast ratio, low reflection and wide viewing angle
 DE (Data Enable) only
 RoHS/Halogen Free
 Gamma Correction
 Reverse type

Application
 Desktop Type of PC & Workstation Use
 Slim-Size Display for Stand-alone Monitor
 Display Terminals for Control System
 Monitors for Process Controller

General Specification

Parameter Specification Unit
Active area 394.56(H)
