7.0 Inch Industrial BOE Monitor Panel TFT 800x480 LCD Display
7.0 Inch Industrial BOE Monitor Panel TFT 800x480 LCD Display
7.0 Inch Industrial BOE Monitor Panel TFT 800x480 LCD Display
7.0 Inch Industrial BOE Monitor Panel TFT 800x480 LCD Display
7.0 Inch Industrial BOE Monitor Panel TFT 800x480 LCD Display
7.0 Inch Industrial BOE Monitor Panel TFT 800x480 LCD Display
7.0 Inch Industrial BOE Monitor Panel TFT 800x480 LCD Display
7.0 Inch Industrial BOE Monitor Panel TFT 800x480 LCD Display
7.0 Inch Industrial BOE Monitor Panel TFT 800x480 LCD Display
7.0 Inch Industrial BOE Monitor Panel TFT 800x480 LCD Display
Specifications
Brand Name :
BOE
Model Number :
QT070WVM-NH0
MOQ :
1PCS
Payment Terms :
T/T
Delivery Time :
3-7work days
Certification :
ISO9001
Place of Origin :
China
Size :
7.0 inch
Resolution :
800*480
Interface :
50 pins RGB
Display Mode :
Normally White
Viewing Direction :
70/70/60/70
Lumiance :
350 cd/m² (Typ.)
Active Area(mm) :
153.84 × 85.632 (H×V) mm
Outline Dimension :
164.9 × 100 (H×V×D) mm
Operation Temp :
-20℃ ~ +70℃
Storage Temp :
-30℃ ~ +80℃
Description

7.0 Inch Industrial BOE Monitor Panel TFT 800x480 LCD Display

QT070WVM-NH0.pdf

BOE 7.0inch 800*480 display for medical monitors

QT070WVM-NH0 is a 7.0-inch a-Si TFT-LCD liquid crystal module product launched by BOE, it is equipped with WLED backlight, no backlight driver, no touch. The operating temperature of this product is -20 ~ 70°C, and the storage temperature is -30 ~ 80°C. Its features are: white LED backlight, up/down, left/right flip display, matte surface, FPC length 80.15. This model is used in household appliances and other products. This product will be mass-produced in Q4 2020, and the current production status is in mass production.

7.0 Inch Industrial BOE Monitor Panel TFT 800x480 LCD Display

Why choose us?

1. Core team from Tianma, Innolux, TFT-LCD and Touch panel field with more than 20 years of experience.

2. Focus on industrial/medical/automotive, products with long lifetime, long-term supply features.

3. Strict quality management, passed ISO9001/ IATF16949/ ISO14001/ ISO13485 certification,0.5‰ after-sales repair rate.

4. One-stop solution provider, support customize TFT-LCD/ Touch Panel with optical bonding/ Signal conver board products,we display your ideas.


7.0 Inch Industrial BOE Monitor Panel TFT 800x480 LCD Display
