Part Number:D38999/20WJ35PN

Product Description:

MIL-DTL-38999 Series Ⅲ is a military standard connector that meets the highest performance requirements for a variety of applications. It is designed for high-reliability and harsh environments. It features a voltage rating of 500V, contact material of copper alloy, operating temperature range of -55°C to +125°C, threaded coupling type, and gold contact finish. This connector is designed to meet the toughest military requirements and is highly reliable and durable for use in military, aerospace, and other demanding applications.

MIL-DTL-38999 Series Ⅲ connectors provide superior performance in extreme environmental conditions, and are suitable for use in a variety of applications, including high-reliability military and aerospace applications. The connectors are manufactured to the highest quality standards and feature a robust design and reliable contact performance. The gold contact finish provides excellent electrical and wear performance, and the threaded coupling type ensures secure and reliable connection.

The MIL-DTL-38999 Series Ⅲ connector is the ideal solution for harsh-environment applications, providing superior performance and reliable operation. It is designed to meet the most demanding military requirements and is a reliable, durable, and cost-effective solution for a variety of applications.

Features:

• Product Name: MIL-DTL-38999 Series Ⅲ Receptacle
• Shell Size: 25
• Number of Contacts: 128
• Shell Finish: Olive Green Cadmium
• Operating Temperature: -55°C To +125°C
• Contact Material: Copper Alloy

Technical Parameters:

Applications:

MIL-DTL-38999 Series Ⅲ manufactured by KAIDA is a military-grade connector series specifically designed for high-reliability applications. The model number for this product is D38999/20WJ35PN, which is manufactured in China with 25 shell size. It is constructed with copper alloy material for contacts and has an operating temperature ranging from -55°C to +125°C. It is also rated for 7 A of current and has a gold contact finish. This product meets the MIL-DTL-38999 Series Ⅲ specification, which is a standard for high-quality connectors used in military and aerospace applications. It is designed for harsh environments and is suitable for applications where maximum reliability is needed.

Customization:

Customized services for MIL-DTL-38999 Series Ⅲ, with Receptacle connector type, Olive Green Cadmium shell finish, and Threaded coupling type.

Brand Name: KAIDA

Model Number: D38999/20WJ35PN

Place of Origin: China

Current Rating: 7 A

Operating Temperature: -55°C To +125°C

Support and Services:

MIL-DTL-38999 Series Ⅲ provides technical support and services, which include:

• Design consultation
• Software and hardware updates
• Product maintenance and repair
• Technical support and troubleshooting
• Training and education

Packing and Shipping:

MIL-DTL-38999 Series Ⅲ connectors will be packaged in accordance with the manufacturer’s recommended guidelines. When shipping, they should be placed in sealed containers with moisture and dust protection. They should be handled with extreme care to prevent damage.

FAQ:

Q:What is the Brand Name of MIL-DTL-38999 Series Ⅲ?

A:The Brand Name of MIL-DTL-38999 Series Ⅲ is KAIDA.

Q:What is the Model Number of MIL-DTL-38999 Series Ⅲ?

A:The Model Number of MIL-DTL-38999 Series Ⅲ is D38999/20WJ35PN.

Q:Where is MIL-DTL-38999 Series Ⅲ made?

A:MIL-DTL-38999 Series Ⅲ is made in China.

Q:What are the key features of MIL-DTL-38999 Series Ⅲ?

A:MIL-DTL-38999 Series Ⅲ features a high degree of ruggedness, durability and reliability, and is suitable for use in high vibration environments.

Q:What type of applications is MIL-DTL-38999 Series Ⅲ suitable for?

A:MIL-DTL-38999 Series Ⅲ is suitable for aerospace, military, industrial, and other harsh environment applications.

D38999 Series 3 Datasheet.pdf
