Specifications
Brand Name :
KAIXIN
Model Number :
KX-Alloy MO500
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
200KG
Price :
To negotiate
Payment Terms :
T/T, L/C
Supply Ability :
50~80 TONS per MONTH
Delivery Time :
45~60days
Packaging Details :
Wooden Box, size as per guests' request
Shape :
Wire,Strip,Rod,Tube,Plate
Alloy Type :
Nickel-cu-al Alloy
Raw Materials :
NI63%,CU27-33%,AL2.3-3.15%
Executive Standard :
ASTM
Delivery status :
Sosoloid
Application :
Applications for Aero engine, shipbuilding, papermaking equipment parts
Features :
Corrosion resistance, wear resistance and heat resistance
Size :
Negotiable
Description

KX Monel K-500 Sheet Welding Wire Strip Round Bar Light Rod Process Performance On Monel Alloy

Product Description and Application

Monel K-500 is also known as UNS N05500

Monel K-500 alloy has comparable corrosion resistance to Monel 400, but has higher mechanical strength and hardness. It has good heat resistance and long-term structure stability. It is mainly used in the manufacture of turbine blades and gas turbine blades with operating temperature below 750℃ on aeroengines. It is also used for making fasteners and springs on ships, Pump and valve parts on chemical equipment, pulp blade on paper making equipment and etc.

Process Performance and Requirements

  • Product Fusion Process

Vacuum Induction Furnace(VIM) and Electroslag Remelting Furnace(ESR)

  • Product Chemical Composition

Alloy % Ni Cu Al Ti Fe Mn S C Si

Monel

K-500

 Min 63 27.0 2.30 0.35
Max 33.0 3.15 0.85 2.0 1.5 0.01 0.25 0.5

  • Product Physical Property

Density 8.44g/cm³
Melting Point 1315-1350℃

  • Product Mechanical Property

Alloy and State

Tensile Strength

Rm N/mm2

Yield Strength

RP0.2N/mm2

Elongation

A5 %

Monel K500

 1100 790 20

  • Productive Process

ASTM Monel Alloy K 500 Sheet / Welding Wire / Strip / Round Bar / Rod

  • Professional Customization

Cold-drawn Wire ¢0.3~¢18mm(Delivery in rolls or trays)
Hot-Rolling Wire ¢5.5~¢20mm(Delivery in rolls)
Strip thickness 0.1~4.5*width 6~350mm(Supply in rolls or straight strips)
Smooth Forged Rod on a Lathe

¢60~350mm,L800-2500mm
Hot-rolled Burnishing ¢20~80mm,L1000-5000mm
Cold Drawn and Burnishing ¢2.5~18mm,L1000-8000mm
Seamless Tube ¢1~275mm,wall thickness 0.2~30,L1000-8000mm
