Specifications
Brand Name :
KAIXIN
Model Number :
KX-Alloy690
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
200KG
Price :
To negotiate
Payment Terms :
T/T, L/C
Supply Ability :
50~80 TONS per MONTH
Delivery Time :
45~60days
Packaging Details :
Wooden Box, size as per guests' request
Shape :
Wire,Strip,Rod,Pipe,Plate
Alloy Type :
Chrome-nickel Alloy
Raw Materials :
NI60%,CR30.39%
Executive standard :
ASTM
Delivery State :
Sosoloid
Application :
Steam generator tubes, baffles, tubes and hardware used in nuclear power generation.
Features :
High chromium-nickel alloy with excellent corrosion resistance to water medium and high temperature environment. It has the characteristics of high strength, good metallurgical stability and good processing performance.
Size :
Negotiable
Description

KX NS315 Nickel Alloy Wire Round Bar Tube Steel Sheet Light Rod on Inconel Alloy

Product Description and Application

NS315 is also knows as UNS N06690, W.N.2.4642, ISO NW6690

NS315 is a high chromel-nickel alloy with excellent corrosion resistance to many corrosive water medium and high temperature atmospheres. In addition to corrosion resistance, it also has high strength, good metallurgical stability, good processing performance and etc characteristics. The high chromium content makes the alloy excellent resistance to oxidizing chemicals and high temperature oxidizing gases. The high nickel content gives resistance to stress corrosion cracking in chlorinated environments and in sodium hydroxide solutions. Properties suitable for various applications of nitric acid or nitric acid/hydrofluoric acid solutions. For example, tail gas reheaters for nitric acid production and heating, nitric acid/hydrofluoric acid solution heating coils and tanks for pickling stainless steel and nuclear fuel reprocessing. The alloy resistance to sulfur-containing gases makes them attractive materials for radioactive waste disposal such as coal gasification units, burners and for sulfuric acid conduits treatment, furnace petrochemical processing, co-flow heat exchangers, incinerators and glass vitrification equipment.

Process Performance and Requirements

  • Product Fusion Process

Vacuum Induction Furnace(VIM) and Electroslag Remelting Furnace(ESR)

  • Product Chemical Composition

Ni Cr Fe C Al Ti Mn Si Cu P S
Rem 30.39 8.88 0.023 0.22 0.26 0.23 0.07 0.02 0.006 0.002

  • Product Physical Property

Density Melting Point
8.19g/cm3 1343-1377℃

  • Product Mechanical Property

Diameter/Thickness

d/t mm

Hot Treatment

or State

 Tensile Strength MPa

Yield Point

MPa

 Elongation after breaking %
t=3.81(strip,cold rolled) 1040℃ Annealing 724 348 41
d=16(bar, hot rolled) 1040℃ Annealing 738 372 44
d=51(bar, hot rolled) 1040℃ Annealing 690 334 50
d=12.7(pipe,cold drawing) 1040℃ Annealing 758 461 39
d=19(pipe,cold drawing) 1040℃ Annealing 700 379 46
d=88.9(pipe, cold drawing) 1040℃ Annealing 648 282 52

  • Productive Process

NS315 690 Inconel Alloy Inconel Round Bar Tube Inconel Sheet Nickel Alloy Wire

  • Professional Customization

Cold-drawn Wire ¢0.3~¢18mm(Delivery in rolls or trays)
Hot-Rolling Wire ¢5.5~¢20mm(Delivery in rolls)
Strip thickness 0.1~4.5*width 6~350mm(Supply in rolls or straight strips)
Smooth Forged Rod on a Lathe

¢60~350mm,L800-2500mm
Hot-rolled Burnishing ¢20~80mm,L1000-5000mm
Cold Drawn and Burnishing ¢2.5~18mm,L1000-8000mm
Seamless Tube ¢1~275mm,wall thickness 0.2~30,L1000-8000mm

NS315 690 Inconel Alloy Inconel Round Bar Tube Inconel Sheet Nickel Alloy WireNS315 690 Inconel Alloy Inconel Round Bar Tube Inconel Sheet Nickel Alloy WireNS315 690 Inconel Alloy Inconel Round Bar Tube Inconel Sheet Nickel Alloy WireNS315 690 Inconel Alloy Inconel Round Bar Tube Inconel Sheet Nickel Alloy Wire
