Specifications
Brand Name :
KAIXIN
Model Number :
KX-Alloy IN601
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
200KG
Price :
To negotiate
Payment Terms :
T/T, L/C
Supply Ability :
50~80 TONS per MONTH
Delivery Time :
45~60days
Packaging Details :
Wooden Box, size as per guests' request
Shape :
Wire,Strip,Rod,Pipe,Plate
Alloy Type :
Nickel-chrome-iron Alloy
Raw Materials :
NI63%,CR21-25%,Fe10-15%
Executive standard :
ASTM
Delivery State :
Sosoloid
Application :
It is used for heat treatment equipment such as industrial furnaces, baskets, Muffle furnaces and distillation tanks, steel wire annealing tubes, petrochemical and other process equipment, burner nozzles, gas turbine equipment, superheater tube supports an
Features :
Excellent corrosion resistance and oxidation resistance
Size :
Negotiable
Description

KX NS313 Nickel Alloy Wire Round Bar Tube Steel Sheet Light Rod on Inconel Alloy

Product Description and Application

NS313 is nickel-chromite alloy with aluminum that has excellent oxidation resistance and other high-temperature corrosion as well as improved resistance to nitriding. It also has high mechanical properties at high temperatures, which is used in heat treatment plant for pallet, basket and fixture, exhaust system components, pipe support and soot treatment components.

Process Performance and Requirements

  • Product Fusion Process

Vacuum Induction Furnace(VIM) and Electroslag Remelting Furnace(ESR)

  • Product Chemical Composition

Alloy % Ni Cr Fe C Mn Si Cu Al P S
NS313 Min Rem 21 10 1.0
Max 25 15 0.1 1 0.5 1 1.7 0.03 0.015

  • Product Physical Property

Density 8.1 g/cm3
Melting Point 1320-1370℃

  • Product Mechanical Property

Alloy State

Tensile strength

Rm N/mm2

Yield strength

RP0.2 N/mm2

Percentage Elongation

A5 %

Brinell Hardness

HB
Annealing Treatment 650 300 30 -
Solution Treatment 600 240 30 ≤220

  • Productive Process

NS313 Alloy 601 Round Bar ASTM Nickel Alloy Wire Inconel Tube Inconel Sheet

  • Professional Customization

Cold-drawn Wire ¢0.3~¢18mm(Delivery in rolls or trays)
Hot-Rolling Wire ¢5.5~¢20mm(Delivery in rolls)
Strip thickness 0.1~4.5*width 6~350mm(Supply in rolls or straight strips)
Smooth Forged Rod on a Lathe

¢60~350mm,L800-2500mm
Hot-rolled Burnishing ¢20~80mm,L1000-5000mm
Cold Drawn and Burnishing ¢2.5~18mm,L1000-8000mm
Seamless Tube ¢1~275mm,wall thickness 0.2~30,L1000-8000mm

NS313 Alloy 601 Round Bar ASTM Nickel Alloy Wire Inconel Tube Inconel Sheet

NS313 Alloy 601 Round Bar ASTM Nickel Alloy Wire Inconel Tube Inconel SheetNS313 Alloy 601 Round Bar ASTM Nickel Alloy Wire Inconel Tube Inconel SheetNS313 Alloy 601 Round Bar ASTM Nickel Alloy Wire Inconel Tube Inconel SheetNS313 Alloy 601 Round Bar ASTM Nickel Alloy Wire Inconel Tube Inconel Sheet
