Specifications
Brand Name :
KAIXIN
Model Number :
KX-Alloy686
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
200KG
Price :
To negotiate
Payment Terms :
T/T, L/C
Supply Ability :
50~80 TONS per MONTH
Delivery Time :
45~60days
Packaging Details :
Wooden Box, size as per guests' request
Shape :
Wire,Strip,Rod,Pipe,Plate
Alloy Type :
Nickel-based Deformed Superalloy
Raw Materials :
NI Rem%,CR19-23%,MO15-17%
Executive standard :
ASTM
Delivery State :
Sosoloid
Application :
Applications for resistance to corrosive medium in chemical processing, pollution control, pulp,paper manufacturing and waste management.
Features :
Corrosion resistance and oxidation resistance
Size :
Negotiable
Description

KX Inconel 686 Nickel Alloy Wire Round Bar Tube Steel Sheet Light Rod on Inconel Alloy

Product Description and Application

Inconel 686 is also known as UNS N06686, W.N.2.4606

Inconel 686 is a single-phase austenitic Ni-Cr-Mo-W alloy with excellent corrosion resistance and reduction resistance in a range of harsh environments. Oxidizing medium that helps resist local corrosion,such as pitting. It can be made into pipes and storage tanks, reactors and heat exchangers, as well as offshore oil well production equipment.

Process Performance and Requirements

  • Product Fusion Process

Vacuum Induction Furnace(VIM) and Electroslag Remelting Furnace(ESR)

  • Product Chemical Composition

Cr Mo W Ti Fe C Mn S Si P Ni
19-23 15-17 3.0-4.4 0.02-0.25 ≤1.0 ≤0.01 ≤0.75 ≤0.02 ≤0.08 ≤0.04 Rem

  • Product Physical Property

Density 8.4g /cm³
Melting Point

1370-1420℃

  • Product Mechanical Property

Tensile Strength 550 MPa

Yield Strength

(0.2% Offset Yield Point)

 240 MPa
Elongation 35%
  • Productive Process

Oxidation Resistance 686 Inconel Alloy Bar Tube Sheet Nickel Chromium Resistance Wire

  • Professional Customization

Cold-drawn Wire ¢0.3~¢18mm(Delivery in rolls or trays)
Hot-Rolling Wire ¢5.5~¢20mm(Delivery in rolls)
Strip thickness 0.1~4.5*width 6~350mm(Supply in rolls or straight strips)
Smooth Forged Rod on a Lathe

¢60~350mm,L800-2500mm
Hot-rolled Burnishing ¢20~80mm,L1000-5000mm
Cold Drawn and Burnishing ¢2.5~18mm,L1000-8000mm
Seamless Tube ¢1~275mm,wall thickness 0.2~30,L1000-8000mm

Oxidation Resistance 686 Inconel Alloy Bar Tube Sheet Nickel Chromium Resistance Wire

Oxidation Resistance 686 Inconel Alloy Bar Tube Sheet Nickel Chromium Resistance WireOxidation Resistance 686 Inconel Alloy Bar Tube Sheet Nickel Chromium Resistance WireOxidation Resistance 686 Inconel Alloy Bar Tube Sheet Nickel Chromium Resistance WireOxidation Resistance 686 Inconel Alloy Bar Tube Sheet Nickel Chromium Resistance WireOxidation Resistance 686 Inconel Alloy Bar Tube Sheet Nickel Chromium Resistance WireOxidation Resistance 686 Inconel Alloy Bar Tube Sheet Nickel Chromium Resistance Wire
