Specifications
Brand Name :
KAIXIN
Model Number :
KX-Alloy EX50
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
200KG
Price :
To negotiate
Payment Terms :
T/T, L/C
Supply Ability :
50~80TONS per MONTH
Delivery Time :
45~60days
Packaging Details :
Wooden Box, size as per guests's request
Shape :
Wire,Strip,Rod,Tube,Plate
Alloy Type :
Fe-Ni Constant Expansion Alloy
Raw Materials :
NI51.5-52.5%,Fe Rem
Executive standard :
ASTM
Delivery State :
Soft State
Application :
For aerospace, nuclear energy, petroleum industry, electric vacuum industry, soft glass or ceramic matching sealing.
Features :
High strength and corrosion resistance
Size :
Negotiable
Description

KX 4J52 Corrosion Resistant Alloy Light Rod On Expansion Alloy

Product Description and Application

4J52 is something like Alloy 50

4J52 has excellent comprehensive properties in the temperature range from -253 ℃ to 700℃. The yield strength below 650℃ ranks the first among deformed superalloys, and has excellent performance, machining performance and welding performance. It can manufacture all kinds of parts with complex shapes, and has been widely used in aerospace, nuclear energy, petroleum industry and extrusion mold in the above temperature range.

Process Performance and Requirements

  • Product Fusion Process

Vacuum Induction Furnace(VIM) and Electroslag Remelting Furnace(ESR)

  • Product Chemical Composition

Alloy Grade C P S Mn Si Al Co Ni Fe
Not more than
4J52 0.05 0.02 0.02 0.6 0.3 ---- --- 51.5～ 52.5 Rem

  • Product Mechanical Property

WireTensile Strength

State Code State Tensile strength/MPa
R Soft State <590
I Hard State >820

Strip Tensile Strength

State Code State

Tensile strength

/MPa
R Soft State <570
I Hard State >700

  • Product Average Coefficient of Linear Expansion

Alloy Grade Sample Heat Treatment Institution

Average Coefficient of Linear Expansion

α/(10-6/ K)
20～ 300℃ 20～ 400 ℃ 20～ 450 ℃
4J52 It is heated to 850±20 ℃ in hydrogen atmosphere, heat preservation for 1 hour and cool to less than 200 ℃ at a speed of no more than 5 ℃ / min 9.8～ 11.0 9.81～ 11.0

  • Product Melting Temperature Range

Melting Temperature 1430℃
Thermal Conductivity λ=16.7W/(m·℃)[1,2]
Specific Heat Capacity 502J/(kg/℃)

  • Productive Process

4J52 Expansion Alloy Corrosion Resistant Alloy Light Rod

  • Professional Customization

Cold-drawn Wire ¢0.3~¢18mm(Delivery in rolls or trays)
Hot-Rolling Wire ¢5.5~¢20mm(Delivery in rolls)
Strip thickness 0.1~4.5*width 6~350mm(Supply in rolls or straight strips)
Smooth Forged Rod on a Lathe

¢60~350mm,L800-2500mm
Hot-rolled Burnishing ¢20~80mm,L1000-5000mm
Cold Drawn and Burnishing ¢2.5~18mm,L1000-8000mm
Seamless Tube ¢1~275mm,wall thickness 0.2~30,L1000-8000mm

4J52 Expansion Alloy Corrosion Resistant Alloy Light Rod

4J52 Expansion Alloy Corrosion Resistant Alloy Light Rod4J52 Expansion Alloy Corrosion Resistant Alloy Light Rod4J52 Expansion Alloy Corrosion Resistant Alloy Light Rod4J52 Expansion Alloy Corrosion Resistant Alloy Light Rod
